300/500v pvc insulated circular cable
- 1000000 Kilometer / Kilometers per Month
- Main Ports of China
- T/T L/C D/P D/A
- Power Accessories Photovoltaic lines Wires UL10269 high voltage cable
- Factory Direct House Wiring 2.5mm2 Single Core Flexible Copper Wire Electrical Wire Installation Electric Cables Price
- XTW CXWT 300V UL62 PVC FIexible Cord
- Enameled Copper wire
- 3x185mm2 Overhead Insulated Cable
- Service Drop Cable XLPE/PVC/PE Insulated
Product Details
Place of Origin: | China | Brand Name: | JYTOP | Model Number: | 300/500v pvc insulated circular cable |
Type: | Insulated | Application: | Other, General purpose | Conductor Material: | Copper |
Conductor Type: | Other, Stranded or Solid | Insulation Material: | PVC |
Product Description
Specifications
300/500v pvc insulated circular cableReference No 3184Y
Four Core
PVC insulated
May be you are also interested about
300/300V PVC Insulated Parallel Flexible Cords to BS 6500
300/500V PVC Insulated Twisted Twin Flexible Cords to BS 6500
300/300V PVC Insulated PVC Sheathed Parallel Twin Light Flexible Cords to BS 6500
300/500V Copper conductor PVC insulated flexible wire 3cores
300/500V PVC Insulated Twisted Twin Flexible Cords to BS 6500
300/500v pvc twin flat cable
Why Choose us?
For over 20 years, Zhengzhou Jinyuan Wire and Cable Co., Ltd., as a professional cable manufacturer has been producing customized cable for a wide range of applications based on high quality, excellent service and competitive market prices. This is an elite team with experienced personnel and strong technical support. Our achievements benefit by having access to the largest market for cheap labor and abundant resources in China and our determination to exceed our clients’ expectations.
PRODUCTS & STANDARDS
We can produce more than 2,000 types of cables and wires, such as
Bare Conductor: AAC, AAAC, ACSR, ACSR/AW, ACAR, ACSS, ACSS/AW, Aluminum Clad Steel Wire/Strand, Bare Copper Conductors, Copper Clad Steel Wire/Strand, Copper Clad Aluminum(CCA), Galvanized Steel Wire/Strand, etc.
Overhead Insulated Cable: Covered Line Single Core Cable and Aerial Bundled Cable (ABC). ABC includes Duplex, Triplex, Quadruplex and more Cores Service Drop Cable.
PVC Insulated Wire up to 450/750V
PVC or XLPE Insulated Power Cable from 1kV to 36kV
Control Cable
Welding Cable
Rubber Cable
We can produce cables according to the standards of IEC, ASTM, EN (BS, DIN, NF, etc.), AS/NZ and meet customers’ special requirements.
ACHIEVEMENTS & COMMITMENT
Our cable has been exported to South-East Asia, South Asia, Middle-East, Europe, North and South America, Africa, Australia & New Zealand and so on. Zhengzhou Jinyuan Wire and Cable Co., Ltd.’s commitment is to be recognized as a zero-defect world class manufacturer in cable industry through continuous improvement of our quality, processes, and products, and by our determination to exceed our clients’ expectations.
300/500v pvc insulated circular cable
Specifications
Reference No 3184Y
Four Core
Size of conductor | Nominal thickness of insulation
mm | Nominal thickness of sheath
mm | Mean overall dimensions | Approx. net weight per km
kg | ||
Nominal cross- sectional area
mm2 | Number and diameter of wires
no/mm |
Lower limit
mm |
Upper limit
mm | |||
0.75 | 24/0.20 | 0.6 | 0.8 | 6.8 | 8.6 | 78 |
1.0 | 32/0.20 | 0.6 | 0.9 | 7.6 | 9.4 | 110 |
1. 5 | 30/0.25 | 0.7 | 1.0 | 9.0 | 11.0 | 150 |
2.5 | 50/0.25 | 0.8 | 1.1 | 10.5 | 13.0 | 220 |
Notes
1.Conductors of high conductivity copper wires insulated with PVC compound.
sheathed with PVC compound.
2.Core colors green/yellow, black, blue and brown Sheathed colors: grey. white or black.
