Specifications
1.4port 10/100M RJ-452.1port 100Base-Fx ,Single or multi mode
3.Port base VLAN
4.Supports MAC self-learning
5.1-3days
Product Name: 5 port 100M fiber switch
4port 10/100M RJ-45
1port 100Base-Fx ,Single or multi mode.
Store and forward mode
10/100M auto-negotiation, maximum speed to 20/200M (full-duplex)
Supports IEEE 802.3x full-duplex flow control and back pressure half-duplex flow control
Supports MAC self-learning
Automatic MDI/MDI-X configuration
Port base VLAN
LED status of Link, activity, Full/half duplex, speed,and power on diagnostic function
Steel case
Order information
OFS-400M | 10/100M 4 RJ45+1 optic port 1310nm 2KM multimode SC fiber switch |
OFS-400S20 | 10/100M 4 RJ45+1 optic port 1310nm 20KM singlemode SC fiber switch |
OFS-400WS20A/B | 10/100M 4 RJ45+1 optic port 1310nm/1550nm 20KM WDM SM SC fiber switch |
OFS-700M | 10/100M 7 RJ45+1 optic port 1310nm 2KM multimode SC fiber switch |
OFS-700S20 | 10/100M 7 RJ45+1 optic port 1310nm 20KM singlemode SC fiber switch |
OFS-700WS20A/B | 10/100M 7 RJ45+1 optic port 1310nm/1550nm 20KM WDM SM SC fiber switch |
