Cellular GSM CDMA 2G 3G 4G Cellphone WiFi Bluetooth Signal Blocker Jammer Antenna Outdoor Omni Antenna

Cellular GSM CDMA 2G 3G 4G Cellphone WiFi Bluetooth Signal Blocker Jammer Antenna Outdoor Omni Antenna


Product Features

1. IMPROVES SIGNAL STRENGTH & SPEED on all 2G 3G 4G LTE PCS GSM CDMA cellular broadband devices.

2. COMPATIBLE WITH routers, modems & gateways.

3. INTEGRATED FEMALE N CONNECTOR - No additional ground plane is needed.

4. WEATHER RESISTANT sleek high gloss gray fiberglass finish. Includes pole/wall mounting bracket and hardware (mast sold separately).

5. MUST BE CONNECTED VIA 50-OHM COAXIAL CABLE TO AN EXISTING CELLULAR MODEM/ROUTER/RADIO DEVICE. Does not improve signal for cell phones or other devices not directly wired to the antenna.



Product Specification - Omni Fiberglass Antenna Signal Blocker Antenna

Electrical Specifications

Freq. Range: 2400-2483.5MHz 5725-5875MHz (can be tuned according to your request)

Gain: 3-8 dBi

VSWR: ≤2.0

Horizontal Beam width: 360º

Vertical Beam width: 17±3º

Impedance: 50Ω

Polarization: Vertical

Max. Power: 100W

Lightning Protection: DC Ground

Connector: N male or customized



Mechanical Specifications

Antenna Dimension: ф32*600 mm

Radome Color: Black

Rated Wind Velocity: 36.9m/s

Operating temperature: -40~80℃



Antenna length can be customized. Please contact us to design your own antenna type.
