DXD-210 Automatic Shaped-bag Horizontal Packaging Machine

Technical performance:

The packaging machine is under control of PLC.Can realize the filling of powder,granules,liquid and mini-viscous liquip.It is suite for shapped-bag packaging .It also can realize the three-side sealing and four- side sealing easily.It is the most ideal bag-packaging machine up to now.

Performance advantage:

1. Control system----Mitsubishi PLC control system, Filling dose random fine-tuning

2. Control panel----Colour touching-screen,easy-operated , stable and reliable

3. Temperature control: using digital temperature control is intuitive form.

4.Work–bin design----Automatic detection.( Full, automatic stop feeding ;Less, , automatic feeding).( The powder feeding machine is the matching product, the expense is extra)

5.Filling exchanging----Can exchange voious kinds of filling heads,powder,granules ,liquid ,and various

6.Electrical elements---Adopting international famous brand to -ensure the remarkable quality, stability and high precision

7.Machine elements----The parts contacted with the material use the 316 high-quality stainless steel and non-poisonous, anti-corrosive PTEF hose.Other machine parts use the 304 high-class stainless steel.

Including the following components:

 Bag-sending shelf

 Standard horizontal strip heat- sealing device

 Easy tear cutting

 Vacuum openning device

 Automatic material level controller

 Photoelectric tracking detection device

 LCD screen operation system

 Micro-computer controll system

 Frequency conversion control system

 Packing product eduction device

 Date hard- pressing system

duct requirements --- film bag molding. (shapped-bag for customers own)

9. Maintenance condition---Fully accords to the GMP requirements, easy to disassemble and clean.

10.Real-time alarm----Automatic alarming when the fault happens,automatic stopping and alarming when the system

appears serious breakdown

11. Appearance design,----Adoptting high-quality organic glass and maintenance door, convenient operation, beauty and generous

Main technical paremeter:

1.Packing bag width:85mm – 210mm

2.Packing bag height:140mm – 280mm

3.Maximum packing measure:5g - 350g(powder according to the proportion of powder materials have differen

weight,)

4.Voltage: 220V/380V

5.Filling error: ≤±1%

6.Filling speed: 20-60bags/hour

7.Air-consuming amount:0.6 m³/min

8.Overall Dimension:3000mm/ 1100mm/ 2050mm

9..Machine weight: 900 kg
