BV-DS042 16 inch standard gearbox flange type butterfly valve
Flange type butterfly valve is a kind of soft sealing butterfly.It is used in metallurgical, chemical, electrical and municipal engineering and water factories,and other media on the official road for water,oil and air from the cut off fluid or adjust the role of media flow.
Material of flange type butterfly Valve's main pats:
(materials can be customized according to your requirements)
No. |
Pats name |
Materials |
specification |
1 |
body |
gray cast iron ductile iron |
A126 class B Astm A536 |
2 |
O-ring |
PTFE |
-- |
3 |
sleeve |
EPDM |
-- |
4 |
shaft |
Stainless steel |
AISI 316 |
5 |
disc |
Stainless steel |
A351 CF8M |
6 |
seat |
EPDM |
-- |
7 |
pin |
Stainless steel |
A351 CF8M |
Technical data of flange type butterfly valve:
Nominal diameter:DN50~2200mm
Design standards:GB/T12238,EN1092
Installation platform:ISO5211
Length of the structure:GB/T12221,BS5155,EN558
Flange standards:GB/T9113,DIN2501,PN(MPa)1.0~1.6
Testing standards:GB/T13927,API598
Packaging of flange type butterfly valve:
.
1.First,putting the valve into a plastic bag.
2.Second,putting the plastic bag into a wooden box.
Tianjin OTS Valve Manufacturing Co., Ltd., established during the period of China’s reform specializes in all kinds of industrial butterfly valves with 13340 square meters including 8600 square meters work-shop. Fixed assets of RMB20 million as well as some advanced processing equipments, among all 120 staffs (including 15 technicians). As a professional pneumatic valve manufacturer, we can provide strong ability of design, processing, assembling and testing for all Butterfly Valves. Further, as a professional pneumatic valve manufacturer, we are rich in the experience of producing butterfly valves over 10 years, all of the butterfly valves we produced keep up to the advanced standard home and aboard.
Our service tips :
1. Customer always firs,customer satisfaction is our goal.
2. 18 months of quality assurance, let customers buy at ease.
3. We are the real factory sales, we will provide you the best quality products with reasonable price .
If you have any inquiry or any problems about the products, please feel free to contact me, and I am pleased to supply service for you:
