2R1G1B Sports Led Display Board for Football Game With Pitch 20mm

Specifications

High Brightness stadium led display board
1. virtual outdoor screen
2.high color quality.
3.excellent white color balance

High Brightness stadium led display board



main features

1 Rugged mechanical design, easy and fast setup and transportation.

2 Improved brightness, contrast and color produce sharper text and clearer images.

3 Soft, replaceable rubber shades protect LEDs from harm and will not injure players in the event of a collision.

4 Software produces refresh rates of 800 Hz, delivering flicker-free content across all platforms.
Additional rubber bar on the top of cabinets to protect the player.

5 LED Cabinets front IP65,rear IP54.



Recomend product



Pixel Pitch:	20 mm
Pixel Density:	2500 pixels/sqm
Pixel Configuration:	2R1G1B
Module Dimension:	320*160 mm
Module Resolution:	16*8 pixels
Cabinets Dimension:	1280*960 mm
Cabinets Resolution:	64*48 pixels
Brightness:	6000 cd/sqm
Best Viewing Distance:	> 20m
Average Consumption:	320 W/sqm
Max Consumption:	800 W/sqm
Viewing Angle:	Horizontal angle: 120 degree Vertical angle:60 degree
Processing:	12 bit
Ingress Protection:	Front IP65; Rear IP54
Refresh Rate:	600 ~ 4800Hz
LED lifetime:	100,000 hours
Input Voltage:	90 ~ 260VAC,50/60Hz
Operation Humidity:	10% ~ 99%



System Diagram







1. stadiums

2. Basketball and football play courts

3. Other indoor & ourdoor play grounds



After-sale service:

1. Lifetime free maintenance and upgrade.

2. Complaint respond period not exceed 24 hours; maintenance guidance and problem solution supplied in 48 hours.

3. Customer satisfaction tracking report.

4. Free technician training.

5. Full set of documents free of charge, which including installation guidance, software operation manual, easy maintenance manual and control system software CD and so on.

6. Special service for big project, such as stadium, exhibitions, squares and so on.
