LAMP Full Color Outdoor Video Led Screen
US$ 1 - 8,000
MOQ: 1 Square Meter
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
LAMP
Usage:
Outdoor
Payment & Shipping
Payment Methods:
Port of Shipment:
HongKong/ShenZhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
LAMP High Resolution Rental Led Display CurtainUS$ 1 - 8,000MOQ: 1 Square Meter -
LAMP High Resolution Outdoor Colorful Led DisplayUS$ 1 - 8,000MOQ: 1 Square Meter
-
LAMP P18.75 Full Color Led Display for Stage BackgroundNegotiableMOQ: 5 Square Meters
-
LAMP High Resolution Full Color Led Screen Board for StageUS$ 1 - 8,000MOQ: 1 Square Meter
-
LAMP P10 Outdoor DIP Tri-color LED ScreenNegotiableMOQ: 5 Square Meters
Place of Origin
Guangdong, China
Brand Name
LAMP
Usage
Outdoor
Tube Chip Color
Full Color
Display Function
Video
Pixels
Other, 6mm,10.41mm18.75mm,40mm
Specifications
led screenStrict system control and pixel to pixel correction make the image smooth and uniformity.
LAMP full color outdoor video led screen featrues
As a modular system of LED video panels which designed for rental led display and staging market & fixed installations demanded, seele led display series allows you to create your own video imaging design to set your staging apart from the ordinary.
1.Fast assembly
Creative design on the connection structure which could be installed fast and easily without tools. And the assembly or disassembly of single module is applicable for any position on the display.
2.Fan-less
A fan-less design to meet all kinds of quiet occasions.
specification
| Pixel Pitch: | 6 mm | 10.41 mm | 18.75 mm | 40 mm |
| Brightness: | 1500 cd/sqm | 1000 cd/sqm | 5000 cd/sqm | 2000 cd/sqm |
| LED Configuration: | SMD 3 in 1 | SMD 3 in 1 | SMD 3 in 1 | 1R1G1B |
| Pixel Density: | 27777 pixels/sqm | 9227 pixels/sqm | 2844 pixels/sqm | 625 pixels/sqm |
| Viewing Angle(Vertical): | 140° | 140° | 140° | 120° |
| Viewing Angle(Horizontal): | 140° | 140° | 140° | 60° |
| Cabinet Resolution: | 96*96 pixels | 32*96 pixels | 32*32 pixels | 16*32 pixels |
| LED Lifetime: | 100,000 hours | 100,000 hours | 100,000 hours | 100,000 hours |
| Power Consumption(Maximum): | 600 W/sqm | 650 W/sqm | 700 W/sqm | 150 W/sqm |
| Weight: | 10 kg/unit | 3.8 kg/unit | 8 kg/unit | 8.5 kg/unit |
| Processing: | 12 bit | 12 bit | 12 bit | 12 bit |
| Refresh Rate: | 300Hz | 1500Hz | 1500Hz | 600Hz |
| Rotation Angle: | -20° to +20° | -25° to +25°/-15° to +15° | -15° to +15° | -20° to +20° |
| Material: | Aluminum alloy | Aluminum alloy | Aluminum alloy | Aluminum alloy |
| Temperature Range(Operating): | -10 to 40 Degrees Celsius | -20 to 60 Degrees Celsius | -20 to 60 Degrees Celsius | -10 to 40 Degrees Celsius |
| Humidity Range(Operating): | 10% to 99% | 10% to 99% | 10% to 99% | 10% to 99% |
| Protection Rating: | IP 20 | IP 20 | IP 65 | IP 65 |
| Dimension(W*H*D): | 576*576*50 mm | 333*999*30 mm | 600*600*91 mm | 640*1280*91 mm |
| LED Processor | DBSTAR | DBSTAR | LINSN | LINSN |
| Signal: | DVI up to UXGA,SDI, HD-SDI,S-video,compositem,YUV | |||
