Specifications
P40 led stage curtain display1) fast installation structure
2) transparent effect
3) solid reliability
4) light and thin
P40 led stage curtain display
features
1.Fast assembly
Creative design on the connection structure which could be installed fast and easily without tools. And the assembly or disassembly of single module is applicable for any position on the display.
2.Rotatable structure:
Ventilative module which can be rotated to and fro.
3.Fan-less
A fan-less design to meet all kinds of quiet occasions.
4.High power efficiency:
A high efficiency power supply with 83% power efficiency which saves 10% more than normal display.
A true IP65 protection rating, wide operating temperature range and high brightness enable the curtain to be used in most indoor & outdoor applications. Until now, seele led display series includes 18mm&40mm for outdoor application and 6mm&10.41mm for indoor application.
Specification
| Pixel Pitch: | 18.75 mm | 40 mm |
| Brightness: | 5000 cd/sqm | 2000 cd/sqm |
| LED Configuration: | SMD 3 in 1 | 1R1G1B |
| Pixel Density: | 2844 pixels/sqm | 625 pixels/sqm |
| Viewing Angle(Vertical): | 140° | 120° |
| Viewing Angle(Horizontal): | 140° | 60° |
| Cabinet Resolution: | 32*32 pixels | 16*32 pixels |
| LED Lifetime: | 100,000 hours | 100,000 hours |
| Power Consumption(Maximum): | 700 W/sqm | 150 W/sqm |
| Weight: | 8 kg/unit | 8.5 kg/unit |
| Processing: | 12 bit | 12 bit |
| Refresh Rate: | 1500Hz | 600Hz |
| Rotation Angle: | -15° to +15° | -20° to +20° |
| Material: | Aluminum alloy | Aluminum alloy |
| Temperature Range(Operating): | -20 to 60 Degrees Celsius | -10 to 40 Degrees Celsius |
| Humidity Range(Operating): | 10% to 99% | 10% to 99% |
| Protection Rating: | IP 65 | IP 65 |
| Dimension(W*H*D): | 600*600*91 mm | 640*1280*91 mm |
| LED Processor | LINSN | LINSN |
| Signal: | DVI up to UXGA, SDI, HD-SDI, S-video, compositem, YUV | |
