Indoor vivid background video fullcolor LED screen

Specifications

fullcolor led screen
1.Unique design structure
2.Vivid color quality
3.Solid reliability
4.Wide product range

fullcolor LED screen

Features:



1, solid aluminum structure to meet the requirements of thousands time of assemble and disasemble.



2, easy hanging structure support fast installation.



3, 14-bit color processing enable a vivid color quality.



4, 1000HZ refresh rate meet all your needs for broadcasting.



5, top industrial power and data connector from Neutrik enhance the stability for whole system.



6,total solution includes video processor, rental power distribution unit, truss...etc.





Product Specification:



Pixel Pitch:	16 mm
Pixel Density:	3096 pixels/sqm
Pixel Configuration:	2R1G1B
Module Dimension:	256*128 mm
Module Resolution:	16*8 pixels
Cabinets Dimension:	1024*768 mm
Cabinets Resolution:	64*48 pixels
Brightness:	7500 cd/sqm
Best Viewing Distance:	> 16m
Average Consumption:	500 W/sqm
Max Consumption:	1250 W/sqm
Viewing Angle:	Horizontal angle: 120 degree Vertical angle: 60 degree
Processing:	12 bit
Ingress Protection:	Front IP65; Rear IP54
Refresh Rate:	>600Hz
LED lifetime:	100,000 hours
Input Voltage:	90 to 260VAC, 50/60Hz
Operation Humidity:	10% to 99%









System Diagram
