Product image
---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
Product data
------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
UT206A is a low power consumption and stable performance, safe and reliable 3 3/4 AC digital clamp meter, overload protection circuit of full scale, unique design makes special electrical instrument superior performance.
An ideal tool for the maintenance and maintenance of smelting, manufacturing, petroleum, electric power, chemical and other industries.
------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
Product attribute
------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
| Specifications | Range | Best Accuracy |
| Model | UT206A | |
| AC Current (A) | 400A/1000A | ±(1.5%+5) |
| AC Voltage (V) | 4V/40V/400V/600V | ±(1.2%+5) |
| DC Voltage (V) | 400mV/4V/40V/400V/600V | ±(0.8%+1) |
| Resistance (Ω) | 400Ω/4KΩ/40KΩ/400KΩ/4MΩ/40MΩ | ±(1%+2) |
| Frequency (Hz) | 10Hz~10MHz | ±(0.1%+3) |
| Temperature (°C) | -40 °C ~ 1000°C | ±(2%+8) |
| Features | ||
| Display Count | 4000 | |
| Auto Range | √ | |
| Jaw Capacity | 40mm | |
| Diode | √ | |
| Auto Power Off | √ | |
| Continuity Buzzer | √ | |
| Low Battery Indication | √ | |
| Data Hold | √ | |
| Relative Mode | √ | |
| LCD Backlight | √ | |
| Full Icon Display | √ | |
| Input Impedance for DCV | Around 10MΩ | √ |
| General Characteristic | ||
| Power | 9V Battery(6F22) | |
| LCD Size | 37mm X 18 mm | |
| Product Color | Red and Grey | |
| Product Net Weight | 350g | |
| Product Size | 236mm X 97mm X40 mm | |
| Standard Accessories | Battery, Test Lead,Carrying Bag,Point Contact Temperature Probe | |
| Standard Individual Packing | Gift Box, English Manual | |
| Standard Quantity Per Carton | 20 PCs | |
| Standard Carton Measurement | 530mm X 360mm X 385mm (0.073 CBM Per Standard Carton) | |
| Standard Carton Gross Weight | 17Kg | |
------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
