Home > Instruments & Meters > Electronic Instrument > Oscilloscope > Best Digital Storage Oscilloscopes UNI-T UTD2202CM
US$ 426.7 - 448
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
UNI-T
Model Number:
UTD2202CM
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai ningbo
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Best Digital Storage Oscilloscopes UNI-T UTD4102CUS$ 502.9 - 528MOQ: 1 Piece -
Best Digital Storage Oscilloscopes UNI-T UTD4302CUS$ 990.5 - 1,040MOQ: 1 Piece
-
Best Digital Four Channel Storage Oscilloscopes UNI-T UTD4104CUS$ 883.8 - 928MOQ: 1 Piece
-
Best Digital Four Channel Storage Oscilloscopes UNI-T UTD4204CUS$ 1,067 - 1,120MOQ: 1 Piece
-
Best Digital Four Channel Storage Oscilloscopes UNI-T UTD4304CUS$ 1,219 - 1,280MOQ: 1 Piece
Place of Origin
Guangdong, China
Brand Name
UNI-T
Model Number
UTD2202CM
--------------------
Product image
Product Description
1,150,000 wfms/s Waveform Acquisition Rate;
2,16Mpts Memory Depth;
3,800×480,7 inches widescreen LCD displays;
4,Special Print Scree Feature;
5,Edge, Video, Pulse Slop and Alternate trigger functions;
6,24 automatic +2 advanced measurements;
7,Unique waveform recording and replay function;
8,Supports plug-and-play USB storage device. Communication with and remote control of computer through the USB device;
9,6 digital Trigger frequency counter.
Product parameters
| Specification | UTD2202CM |
| Channels | 2 |
| Bandwidth | 200MHz |
| Sample Rate | 1GS/s |
| Rise Time | ≤1.8ns |
| Memory Depth | 16Mpts |
| Waveform Acquisition Rate | ≥150,000wfms/s |
| Vertical Sensitivity | 2mV/div~10V/div |
| Timebase Range | 2ns/div~50s/div |
| Storage | Setup, Wave, Bitmap, CSV |
| Trigger Modes | Edge, Pluse, Video, Slope, Alternate |
| Interface | USB Device, USB Host, Pass/Fail |
| General Characteristic | |
| Power | 100-240VAC, 45-440Hz |
| Display | 7 Inches 64K Color TFT LCD, 800×480 |
| Product Color | White and Gray |
| Product Net Weight | 2.9 Kg |
| Product Size(W×H×D) | 330mm × 155mm × 130mm |
| Standard Accessories | Probe×2(1×,10× switchable),Power Cord,USB Cable,PC Software CD |
| Standard Individual Packing | Gift Box, English Manual |
| Standard Quantity Per Carton | 2 PCs |
| Standard Carton Measurement(L×W×H) | 450mm × 420mm × 280mm |
| Standard Carton Cross Weight | 10 Kg |
| Optional Accessories* | |
| LAN Port, LA Module | |
Qualification
