Product image
---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
Product data
------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
UT120 series is a portable, compact, lightweight 3 3 / 4 bit automatic range pocket type digital million meters, complete functions, stable performance, high precision, low power consumption, novel structure, safe and reliable, simple operation, easy to use, wear resistant, durable, the majority of users to measuring instrument.
It can be used in the fields of family, school, smelting, communication, manufacturing, petroleum, national defence, electric power, chemical industry and so on. It is an ideal tool for electric equipment maintenance and maintenance.
------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
Product attribute
------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
| Specifications | Range | Best Accuracy |
| Model | UT120C | |
| DC Voltage (V) | 4V/40V/400V/600V | ±(0.8%+3) |
| AC Voltage (V) | 4V/40V/400V/600V | ±(1.2%+3) |
| DC Current (A) | 400μA/4mA/40mA/400mA | ±(1.0%+3) |
| AC Current (A) | 400μA/4mA/40mA/400mA | ±(1.5%+5) |
| Resistance (Ω) | 400Ω/4KΩ/40KΩ/400KΩ/4MΩ/40MΩ | ±(1%+2) |
| Capacitance (F) | 4nF/40nF/400nF/4μF/40μF/100μF | ±(4%+3) |
| Frequency (Hz) | 99.99Hz~99.99KHz | ±(0.5%+3) |
| Features | ||
| Display Count | 4000 | |
| Auto Range | √ | |
| Duty Cycle | 0.1%~99.9% | √ |
| Diode | √ | |
| Auto Power Off | Around 30 Minutes | √ |
| Continuity Buzzer | √ | |
| Low Battery Indication | ≤2.4V | √ |
| Data Hold | √ | |
| Relative Mode | √ | |
| Input Impedance for DCV | Around 10MΩ | √ |
| General Characteristic | ||
| Power | 3V Battery(CR2032) | |
| LCD Size | 43mm X 22mm | |
| Product Color | Red and Grey | |
| Product Net Weight | 76g | |
| Product Size | 110mm X 58.2mm X 10.8mm | |
| Standard Accessories | Battery,Carrying Case | |
| Standard Individual Packing | Blister, English Manual | |
| Standard Quantity Per Carton | 90 PCs | |
| Standard Carton Measurement | 528mm X 323mm X 400mm (0.068 CBM Per Export Carton) | |
| Standard Carton Gross Weight | 13.5 Kg | |
------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
