Help CenterAluminum Curtain-wall Porfile Tenon Milling Machine
Related Products
-
Single Head Crimping Machine for Processing Doors and WindowsUS$ 2,030 - 2,030MOQ: 1 Set -
Four Head Combination Drilling Machine for Aluminum Windows and DoorsUS$ 10,000 - 10,000MOQ: 1 Set
-
Aluminum Cutting Machine Double Mitre Saw / Pvc Double Head Mitre SawUS$ 2,080 - 4,900MOQ: 1 Set
-
45 Degree Cutting Machines to Processing Windows and Doors/cutting MachinesUS$ 3,000 - 9,000MOQ: 1 Set
-
45 Degree Cutting Machines to Processing Windows and DoorsUS$ 5,000 - 9,000MOQ: 1 Set
Specifications
profile tenon milling machine, curtain-wall profile tenon milling machine, CNC milling machine, aluminum profile tenon millingprofile tenon milling machine, curtain-wall profile tenon milling machine, CNC milling machine, aluminum profile tenon milling
Welcome to receive your inquiry message to chenzj0706 at hotmail com
Equipment Features:
1. Six combined cutters can assembly any size according to the users’ requirements
2. One time feeding can process the required morties dimension of the profile surface.
3. Milling at any angle between 180º is available
4. Applicable to molding processing for end surface and level surface of a variety of profiles
5. Feeding system adopts motor drag, adjustable speed, uniform cutting and feeding speed,
Accurate processing and high quality
Main specification and technical parameter
Power supply |
380V/50Hz |
Cutting motor power |
13.2kw(six group) |
Motor rotary speed |
2800r/min |
Feeding motor |
0.37KW |
Operation air pressure |
0.5-0.8Mpa |
Motor main shaft diameter |
Φ32mm |
Wortable measurement |
480 x 480mm |
Adjustbale space of cutter |
Φ250Milling cutter 4piecs 14"milling cutter 2 pieces |
Quantity of milling cutter |
horizotal 80mm vertical 280mm cutter 6piecs |
Contour dimension |
2070mmx1130mmx1820mm |
Weight |
1800kgs |
