45 Degree Cutting Machines to Processing Windows and Doors

Name: 45 Degree Cutting Machines to Processing Windows and Doors
Brand: BOHMAN
SKU: 107466091

US$ 5,000 - 9,000 MOQ: 1 Set

Key Specifications

Condition:

New

Place of Origin:

Shandong, China

Brand Name:

BOHMAN

Jinan Bohman Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Place of Origin Shandong, China

Brand Name BOHMAN

Model Number LJZ2450*3700

Voltage 380V 50Hz

Rated Power 3KW

Dimension(L*W*H) 5000x1100x700mm

Weight 1300KGS

Certification BV

Warranty 1 year

After-sales Service Provided Engineers available to service machinery overseas

Specifications

1.45 degree cutting machines
2.double head mitre saw for cutting profile of aluminum win-door

45 degree cutting machines is used for cutting the profile of aluminum doors and windows and curtain-wall profiles, the main features as below:

1.Imported computer control system with the automatic measuring function

2.Using ball bearing to keep the high precision

3.Adopt the size compensation function and it can achivev high repeated location precision

BOHMAN MACHINES IS THE BEST FOR YOUR CAREER

Main specification and technical parameter

Power supply	380V 50Hz
Saw head power	2 x 1.5 Kw 2800r/min
Operation air pressure	0.5-0.8Mpa
Input power	380v 50Hz
power	3.55kw
Motor power	2x1.5kw
Motor rotay speed	2840r/min
Saw rotay speed	3155r/min
Cutting speed stepless speed regulation	0-3m/min
Blade specification(mm)	Φ350xΦ3.0x30mm
Max Cutting width	200mm
Max Cutting deepth	120mm
Cutting length	400~3700mm
Contour dimension	*4600mm1300mm1550mm*
Weight	1300kgs
