Specifications

1.Suitable for different size of container
2.Durable
3.High production capability
4.Tin can welding machine

Semi-automatic pail tinplate can body welding machine/tin can making machines



1.Main technical data

Linear rate of welding	6-18m/min
Production capability	20~80Cans/min
Applicable can diameter	ø65~ø286mm
Applicable can height	70~420mm
Applicable material	Tinplate steel-based  Temper:T2.5-DR8
Applicable material thickness	0.18~0.42mm
Seam welding landing	0.4mm  0.6mm 0.8mm  1.2mm
Seam point distance	0.5~0.8mm
Applicable copper wire diameter	ø 1.38mm ø 1.5mm
Cooling water	Temperature:12-18°C Pressure:0.4~05Mpa Discharge:7L/min
Power	380V±5% 50HZ
Total power	18KVA
Dimension	1200×1100×1800mm
Weight	1200Kg













































*******************************************************

2.Our major component suppliers

1, PLC(Programmable Logic Controller) is purchased from Japanese MITSUBISHI.

2, Low voltage apparatus are produced by SCHNEIDER.

3, IGBT(Insulated Gate Bipolar Transistor) is bought from Japanese FUJI.

4,OMRON is our sensor supplier.

5, HMI(Human Machine Interface) is purchased from WEINTEC Labs.,Inc in Taiwan.



3.Can making technology  process

Cutting-----rounding-----welding-----coating-----drying-----pre-curling and expanding-----flanging-----seaming bottom-----beading and curling



4.Applicable types of products

aerosol cans, food cans, beverage cans, chemical cans , paint pot and square bucket.
