Milling machine
X5036B vertical milling machine is a kind of common metal cutting tools. This tool spindle cone can be directly or through the attachment of cylindrical milling, installation, end milling cutters, Angle cutter knives, applicable to such processing various parts of the plane, cant, groove, holes etc, machinery manufacturing, mould, instrument and meter, automobile, motorcycle industries ideal processing equipment.
This machine has the following features
SPECIFICATIONS |
X5036A |
X5036B |
Spindle taper |
7:24 ISO50 |
7:24 ISO50 |
Distance.spindle to tabie surface mm |
80-44 |
70-450 |
Spindle center to column guideway surface distance mm |
320 |
360 |
Spindle speed range r/min |
60-1700(12) |
60-1690 (12) |
Mill Head rotation angle |
±45° |
±45° |
Table size mm |
1250×360 |
1500×360 |
Table travel (X/Y/Z) mm |
600/320/360 |
1000/320/380 |
Table longitudinal/lateral Speed of mm/min |
22-555(8)810() |
15-370(8)540() |
Table vertical speed motor movements mm/min |
590 |
590 |
Table T-slot number/width/spacing mm |
3/18/80 |
3/18/80 |
Main motor power kw |
4 |
4 |
Table motor power feed motor w |
750 |
750 |
Lift motor power down feed w |
1100 |
1100 |
Cooling pump motor powe w |
90 |
90 |
Cooling pump flow |
25 |
25 |
Machine NW/GW (kg) |
2200/2400 |
2230/2400 |
Overall size(mm) |
1700×1680×1880 |
2220×1790×1980 |
