Vertical Milling Machine
US$ 11500.00 - 12000.00
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Zhejiang, China
Brand Name:
amasun
Payment & Shipping
Payment Methods:
Port of Shipment:
NING BO
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Mini Milling Machine for SaleUS$ 11500.00 - 12000.00MOQ: 1 Set -
Universal Mini Metal Processing Milling MachineNegotiableMOQ: 1 Set
-
Turret Universal Milling Machine ManufacturerUS$ 14800.00 - 15000.00MOQ: 1 Set
-
Convention Turret Milling MachineUS$ 11500.00 - 12000.00MOQ: 1 Set
-
China Professional Metal Processing Milling MachineUS$ 4,000 - 6,000MOQ: 1 Set
Condition
New
Place of Origin
Zhejiang, China
Brand Name
amasun
Model Number
X6132
Type
Vertical
CNC or Not
Normal
Voltage
380V
Power(W)
7.5KW
Dimension(L*W*H)
2294*1770*1665
Weight
3000kg
Certification
ISO
Warranty
1 Year
After-sales Service Provided
Engineers available to service machinery overseas
vertical milling machine
Specifications
| SPECIFICATIONS | X6132 |
| When the Lord taper(mm) | 7:24ISO50 |
| Main shaft centerline to vertical lathe bed guide distance(mm) | 30-350 |
| Main shaft centerline to hang beam distance (mm) | 155 |
| Spindle aperture(mm) | 29 |
| The most DaHuiZhuan Angle | ±45 |
| Spindle speed range(rpm) | 30-1500 |
| Working mesa dimension (mm) | 1325*320 |
| The longitudinal/horizontal/vertical stroke to (mm) |
700(680)/255(240)/320(300)
|
The scope of the longitudinal/horizontal/vertical(mm/mm) |
18step23.5-1180/23.5-1180/8-394 |
| The fast moving speed longitudinal/horizontal/vertical(mm/min) | 2300/2300/770 |
| The" T" type slot slot number/width/spacing(mm) | 3/18/70 |
| Main motor power (kw) | 7.5 |
| Rapid motor power (kw) | 1.5 |
| Overall size(mm) | 2294*1770*1665 |
| Net weight (kg) | 2800/3000 |
