small milling machine
XH400 XYZ axes hard way
Taiwan-made spindle,
Highly rigid resin sand casting
Precise ball screw
Taiwan tools cylinder
Taiwan precise cap nut
Stainless steel dust-proof mask
Automatic intermittent lubrication system
Adjustable plate
Japan NSK bearing
NO. |
ITEM |
Specification |
|||
1 |
Table size L(mm)×W(mm) |
700×250 |
|||
2 |
T slot QTY /width/interval distance(mm) |
3-12-75 |
|||
3 |
Maximum load(KG) |
280 |
|||
4 |
X travel (mm) |
390 |
|||
5 |
Y travel (mm) |
260 |
|||
6 |
Z travel (mm) |
340 |
|||
7 |
Spindle nose to table (mm) |
80-420 |
|||
8 |
Spindle center to column (mm) |
300 |
|||
9 |
Spindle taper |
BT30/100 |
|||
10 |
Max. spindle speed (Rpm) |
6000 or 8000 |
|||
11 |
Main motor (kW) |
2.2 |
|||
|
12
|
Feed motor
|
X torque(N.M) |
4 |
||
Y torque(N.M) |
5 |
||||
Ztorque(N.M) |
6 |
||||
Max. install size |
2.2 |
||||
13 |
Rapid moving speed (m/min.) |
10/10/8 |
|||
14 |
Cutting speed (mm/min) |
1-4000 |
|||
15 |
Ball screw (diametermm/pitch )mm |
25/06 |
|||
16 |
Accuracy
|
Positioning accuracy (mm) |
0.016 |
||
Repeatability accuracy (mm) |
0.008 |
||||
17 |
Tool changer |
Funnel type (optional ) BT30 |
10 or 12 |
||
18 |
Air pressure Mpa |
0.6 |
|||
19 |
Machine weight (kg) |
Frame |
1400 |
||
Complete machine |
2000 |
||||
20 |
Machine overall size : L(mm)×W(mm)×H(mm) |
Frame |
1500×1100×1600 |
||
Complete machine |
2100×1500×2160 |
||||
