6.6m 35 Seats School Bus

Name: 6.6m 35 Seats School Bus
Brand: Wuzhoulong
SKU: 107170835
Availability: InStock

Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)

Key Specifications

Seats:

Other, 28-35

Emission Standard:

Euro 4

Transmission Type:

Manual

Chongqing Wuzhoulong New Energy Automobile Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen or Shanghai port

Delivery Detail:

Delivery time depends on order quantity.

Seats Other, 28-35

Emission Standard Euro 4

Transmission Type Manual

Max Speed 91 - 110 km/h

Steering Position LHD

Fuel Type Diesel

Dimensions (L x W x H) (mm) 6640*2260*2770/2950mm

Place of Origin Chongqing, China

Brand Name Wuzhoulong

Model Number WZL6661AT4-X

Specifications

Dimension: 6640*2260*2770/2950mm
Gross weight: 5500kg
Top speed: 95km/h
With good quality and best price.

Our products can be customized,

small order quantity is acceptable.

6.6m 35 Seats School Bus

Overall Parameter

Overall Length (mm)	6640
Overall Width (mm)	2260
Overall Height (mm)	2270/2950
Wheelbase (mm)	3308
Front/Rear Overhang (mm)	1220/2112
Approaching/Departure Angle (°)	20/15
Front/Rear Tread (mm)	1750/1600
Gross weight (kg)	5500
Rated Passenger	28-35
Top Speed (km/h)	95

Engine Parameter

Model	YC4FA115-40
Manufacturer	YUCHAI
Position/Fuel type	Front/ diesel
Type	Inline ,4 strokes, water-cooling ,turbo-intercool,electricity control.
Max Power (kw/r/min)	85/3200
Max Torque (N.m/r/min)	300/1600-2400
Displacement (L)	2.982
Emission Standard	Euro IV

Chassis Parameter

Model	NJ6581YFD1
Gear box	TC5-35
Clutch	φ325 diaphragm spring clutch.
Front Axle	Forged module, “H”type section, two fist-end type 2.4T
Drive Axle	Integrate instructions 4.2 T Main transmission 5.375
Suspensible	Leaf spring 9/8
Steering	Integrated power steering
Brake	Dual-circuit pneumatic, drum braking.
oil Tank	85L
Tyre	7.00R16 6pcs
battery	105Ah×2/100A 28V
Others	Automatic -adjusting arm, ABS

Body

Body constructure	Semi-monocoque
Interior Trim	Safety sky window, PVC top board
Door and Door pump	MID-pneumatic folding passenger door,Driver door
Window and side wind screen	Full-view laminated windscreen, alloy aluminum sliding side windows.
Rear view system	Manual bracket rear view mirror,inside view mirror.
A/C	12000KCAL/H , top fixed
Heating system/ defrost	Water-heating defrost system
Auto Video system	MP3
Lamp	Integral high and low headlamp, rear combined lamps,3 roof lamps
Rain wiper	Opposed wiper with detergent.
seats	33 seats (3+2 style ) students seats . 1 care seats ,with adjustable driver seat,all seats with safety belt
floor leather	Anti-slipping floor leather
Lacquer	solid Lacquer
Others	Driver door Handle, Vice Driver Handel , extinguisher(4Kg×2), froth rail ,Half driver sun-visor, Electric clock, Roof fan for driver, Travel recorder, fold side curtain, colorful rearing monitor, Alloy type cover, passenger door handle, 5 person seats rail
