8m School Bus

Name: 8m School Bus
Brand: Wuzhoulong
SKU: 107170875

Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)

Key Specifications

Seats:

Other, 24-49

Emission Standard:

Euro 4

Transmission Type:

Manual

Chongqing Wuzhoulong New Energy Automobile Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen or Shanghai port

Delivery Detail:

Delivery time depends on order quantity.

Seats Other, 24-49

Emission Standard Euro 4

Transmission Type Manual

Condition New

Engine Capacity 4 - 6L

Fuel Type Diesel

Place of Origin Chongqing, China

Brand Name Wuzhoulong

Model Number WZL6800AT4-X

Specifications

Dimension: 8000*2260*2810/2980mm
Gross weight: 8600kg
It also can be transportation purpose. With good quality and best price

Our Products can be customized,

small order quantity is acceptable.

8m School Bus

Overall Parameter

Overall Length (mm)	8000
Overall Width (mm)	2260
Overall Height (mm)	2810/2980
Wheelbase (mm)	4250
Front/Rear Overhang (mm)	1220/2530
Approaching/Departure Angle (°)	18/9
Front/Rear Tread (mm)	1900/1660
Gross weight (kg)	8600
Rated Passenger Capacity	24-49
Top Speed (km/h)	85

Engine Parameter

Model	YC4D130-41
Manufacturer	YUCHAI
Position/Fuel type	Front/ Diesel
Type	Inline ,4 strokes, water-cooling ,turbo-intercool,electricity control.
Max Power (kw/r/min)	96/2800
Max Torque (N.m/r/min)	420/1400-1800
Displacement	4.214 L
Emission Standard	Euro IV

Chassis Parameter

Model	NJ6721YFD2
Gear box	Manual five-gear speed with synchronizer
Clutch	φ350 diaphragm spring clutch.
Front Axle	Forged module, “H”type section, two fist-end type 3.5T
Drive Axle	Integrate instructions 6 T ,Main transmission :5.286
Suspension	Leaf spring 3/4
Steering	Integrated power steering
Brake	Double loop air brake ,drum brake ,air-break break system
oil Tank	85L
Tyre	8.25R16 6pcs
Battery	120Ah×2/110A 28V
Others	ABS, Automatic-adjusting arm

Body

Body constructure	Semi-monocoque
Interior Trim	Molding A/C Interior(Without reading Light ,safety window ,PVC board )
Door and Door pump	Middlepneumatic folding passenger door,Driver door.
Window and side wind screen	Full-view laminated windscreen,Steel windshield,alloy aluminum sliding side windows.
Rear view system	Manual bracketrear view mirror,inside view mirror.
A/C	Roof A/C ,16000KCAL/H
Heating system/ defrost	Water-heating defrost system
Auto Video system	MP3
Lamp	Integral high and low headlamp, rear combined lamps,3 roof lamps
Rain wiper	Opposed wiper with detergent.
Seats	46 seats (3+2 style ) students seats .2 care seats ,with adjustable driver seat,all seats with safety belt .
Blanket	Bamboo leather
Lacquer	Soild lacquer
Others	Driver door Handle, Vice Driver Handel, extinguisher(4Kg×2), froth rail ,Half driver sun-visor, Electric clock, Roof fan for driver, Travel recorder, fold side curtain, colorful rearing monitor, Alloy type cover, passenger handle, 5person seats rail
