Safety School Bus

Name: Safety School Bus
Brand: Wuzhoulong
SKU: 107170859

Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)

Key Specifications

Seats:

Other, 56-61

Emission Standard:

Euro 4

Transmission Type:

Manual

Chongqing Wuzhoulong New Energy Automobile Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen or Shanghai port

Delivery Detail:

Delivery time depends on order quantity.

Seats Other, 56-61

Emission Standard Euro 4

Transmission Type Manual

Max Speed 71 - 90 km/h

Steering Position LHD

Fuel Type Diesel

Dimensions (L x W x H) (mm) 9260*2500*3140mm

Place of Origin Chongqing, China

Brand Name Wuzhoulong

Model Number WZL6930AT4-X

Specifications

Dimension: 9260*2500*3140mm
9.3m 56-61 Seats Spacious School Bus, with good quality and best price.

Specification

Overall Parameter

Overall Length (mm)	9260
Overall Width (mm)	2500
Overall Height (mm)	3140
Wheelbase (mm)	5000
Front/Rear Overhang (mm)	1110/3150
Approaching/Departure Angle (°)	20/9
Front/Rear Tread (mm)	2035/1800
Max Weight (kg)	12000
Rated Passenger Capacity	56-61
Top Speed (km/h)	85

Engine Parameter

Model	YC4E160-42
Manufacturer	YUCHAI
Position/Fuel type	Front/ Diesel
Type	Inline ,4 strokes, water-cooling ,turbo-intercool,electricity control.
Max Power (kw/r/min)	118/2600
Max Torque (N.m/r/min)	550/1300-1600
Displacement	4.26 L
Emission Standard	Euro IV

Chassis Parameter

Model	NJ6731YFD2
Gear box	5MT with synchronizer
Clutch	φ380 diaphragm spring clutch.
Front Axle	Forged module, “H”type section, two fist-end type 4.5T
Drive Axle	Integrate instructions 8T
Suspension	Leaf spring 5/6
Steering	Integrated power steering
Brake	ECE standards, dual-circuit pneumatic, drum braking.
oil Tank	120L
Tyre	9.00R20 6pcs
battery	135Ah×2/110A 28V
Others	Automatic-adjusting arm, ABS
