Help Center11.65m (CNG&battery) New Energy Bus
Negotiable
MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Seats:
41 - 60
Emission Standard:
Euro 4
Transmission Type:
Automatic
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen or Shanghai port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
40seats Hybrid Diesel&Battery City BusNegotiableMOQ: 1 Unit -
40 Seats Natural Gas & Battery Hybrid Bus for SaleNegotiableMOQ: 1 Unit
-
30 Seats Diesel & Battery Hybrid Bus for SaleNegotiableMOQ: 1 Unit
-
15-25 Seats Front Engine CNG BusNegotiableMOQ: 1 Unit
-
10.5m 24-40 Seats Luxury City BusNegotiableMOQ: 1 Unit
Seats
41 - 60
Emission Standard
Euro 4
Transmission Type
Automatic
Max Speed
71 - 90 km/h
Steering Position
LHD
Fuel Type
Hybrid
Dimensions (L x W x H) (mm)
11650*2480*3390mm
Place of Origin
Chongqing, China
Brand Name
Wuzhoulong
Model Number
WZL6123HEVGEG4
Specifications
Dimension:11650*2480*3390mmRated passenger:79/24-42
Top speed:75km/h
It can be diesel&battery hybrid or CNG&battery hybrid.
Specification
Overall Parameter
| Overall length (mm) | 11650 |
| Overall width (mm) | 2480 |
| Overall height (mm) | 3390 |
| Wheel base (mm) | 5700 |
| Front/rear overhang (mm) | 2630 / 3320 |
| Approach/departure angle(°) | 7/7 |
| Front/rear overhang (mm) | 2040 / 1860 |
| Gross weight(kg) | 17500 |
| Rated passengers | 79 / 24-42 |
| Top speed (km/h) | 75 |
Engine Parameter
| Engine model | YC6J190N-40 |
| Manufacturer | Yuchai |
| Position /fuel | Rear/CNG |
| Type | Inline ,4 strokes,water-cooling turbo-intercool, electricity control |
| Max power (kw/ r/min) | 140 / 2500 |
| Max torque (N.m/r/min) | 650/ 1500 |
| Displacement | 6.5L |
| Cylinder ×bore (mm) | 105x125 |
| Emission standard | Euro IV |
Chassis Parameter
| Chasis /Manufacture | WZL6123DPHEVGER Chongqing Wuzhoulong |
| Main Motor No./Manu. | YPQ220L-6M (75KW) / Dalian Tianyuan zai |
| Battery No./Manu. | HEV336V100Ah / Guangdong Power Technology Co., Ltd. Wuzhou Long |
| Cluth | φ395 , Electric control ,single .dry style , diaphragm spring |
| Front Axle | Dong feng 6.5T , Forged module, “H”type section, two fist-end type |
| Driving axle | Single-grade reduction, hyperbolic gear |
| Suspension | 5/5 Leaf spring 5/5 |
| Steering | Power steering |
| Brake | Dual circuit air brake with ECE standard,drum brake |
| Gas cylinder | (8*80L) 640L |
| Tyre | 275/70R22.5 6pcs |
| Battery/Generator | 165A.h×2/110A +140A 28V |
