Home > Transportation > Bus > City Bus > 10.5m 24-40 Seats Luxury City Bus

10.5m 24-40 Seats Luxury City Bus

Name: 10.5m 24-40 Seats Luxury City Bus
Brand: Wuzhoulong
SKU: 107169261
Availability: InStock

Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)

Key Specifications

Seats:

21 - 40

Emission Standard:

Other, Euro III Euro IV

Transmission Type:

Automatic

Chongqing Wuzhoulong New Energy Automobile Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen or Shanghai port

Delivery Detail:

Delivery time depends on order quantity.

Seats 21 - 40

Emission Standard Other, Euro III Euro IV

Transmission Type Automatic

Max Speed 71 - 90 km/h

Steering Position LHD

Fuel Type Hybrid

Dimensions (L x W x H) (mm) 10490*2480*3380mm

Place of Origin Chongqing, China

Brand Name Wuzhoulong

Model Number WZL6101PHEVGEG4

Specifications

Dimension: 10490*2480*3380mm
Fuel type: CNG&battery(Diesel&battery is optional)
The leader of new energy automobile.

Our products can be customized,

small order quantity is acceptable.

WZL6101PHEVGEVG4 Hybrid city bus

Engine Parameter

Engine Model	YC 6J210N-40
Engine Position/Fuel	Rear NG & Battery
Engine Type	NG Vertical Inline ,4 strokes, water-cooling turbo-intercool, electricity control
Max Torque(N.m)	710/1500
Max power (km/r/min)	155/2500
Emission standard	6.454 L
Emission standard	Euro IV

Chassis Parameter

Chassis Mode/Manufacture	WZL6100DPHEVGR wuzhoulong
Electric Motor Model /Manu.	YPQ220M-6 (75KW) /Dalian Tianyuan
Battery/Manu.	HEV336V100Ah Guangdong Power Technology Co., Ltd. Wuzhou Long
Clutch	φ395 , Electric control ,single .dry style , diaphragm spring
Front axle	Dongfeng Dana , Forged module, “H”type section, two fist-end type
Driving axle	Dongfeng Dana ,Single-grade reduction, hyperbolic gear
Suspension	Leaf Spring9/11
Steering	Power steering
Brake	Dual-circuit drum braking system according with ECE standard .Automatically air-cut brake. drum type brake
Gas cylinder	(8X80L ) 640L
Tyre	275/70R22.5 6pcs
Storage battery/generator	165A.Hx2/110A+140A 28V

Body
Body construction	Semi-Monocoque
Interior Trim	Integral moulding intenerate interior trim, Yellow spray roller spend handrails, Hang Ring 16 pcs
Door and pump	Front single Pneumatic outward-swing passenger door. Pneumatic door pump
Windblock ,side window	Whole view laminated front windscreen/ Adhesive side window, sliding side window at rear
Rearview system	Pole shape rear view mirror & inner view mirror. The Inner monitor for Rearing the bus.
Warm wind/defrosting	Water heating defrost system
Audio system	MP3
Lights	Front&Rear combination lamp,Long Box Light .
Windscreen wiper	Opposite type wiper with detergent
Seats	28+1 Injection Molding with soft cushioning Pubic city bus seats . Adjustable driver seats.
Floor leather	Anti-slipping chinese floor leather
Lacquer	China Lacquer
A/C	China electric A/C ,Roof style
Others	Extinguisher, (4Kg×2), 2 auto distinguishers in engine compartment, froth rail ,Half driver sun-visor , 4 Safety hammers, front & Rear luminescence Road Line, air filter access door, colorful Rearing Monitor, electric Clock , gas control system.
