Natural Gas City Bus

Name: Natural Gas City Bus
Brand: Wuzhoulong
SKU: 107166311
Availability: InStock

US$ 67,000 - 80,000 MOQ: 1 Unit

Key Specifications

Seats:

Other, 24-42

Emission Standard:

Euro 4

Transmission Type:

Manual

Chongqing Wuzhoulong New Energy Automobile Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen or Shanghai port

Delivery Detail:

Delivery time depends on order quantity.

Seats Other, 24-42

Emission Standard Euro 4

Transmission Type Manual

Max Speed 71 - 90 km/h

Steering Position LHD

Fuel Type Hybrid

Dimensions (L x W x H) (mm) 11650*2480*3390mm

Place of Origin Chongqing, China

Brand Name Wuzhoulong

Model Number WZL6123NG4

Specifications

11.6m 24-42 Seat City Bus
Size:11650*2480*3390mm
Rated passenger:60/24-42
Top speed: 75km/h

Our products can be customized, small order quantity is acceptable.

11.6m 24-42 Seat City Bus

Engine Parameter

Engine model	YC6G230N-40
Manufacturer	YUCHAI
Position /fuel	Rear/ CNG
Type	Inline, 4 stroke, water cooler, turbo charge, inter cooler, electronic control
Max power (ps/r/min)	170 / 2500
Max torque (N.m/r/min)	850 / 1400
Displacement (L)	7.8
Cylinder ×bore (mm)	112x132
Emission standard	Euro IV

Chassis Parameter

Model	NJ6111YBC1 Nianjing Iveco
Transmission	SG5-90/Shaoguang
Clutch	φ420 single , dry, diaphragm spring clutch
Front Axle	Dongfeng 6.5T Forged module, “H”type section, two fist-end type
Driving Axle	Dongfeng 11T Single-grade reduction, hyperbolic gear
Suspension	Leaf spring F/R: 5/5
Steering	Integral power steering
Brake	Dual circuit air brake with ECE standard ,Drum brake
Gas cylinder	(720L=6*120L) Electric gas leakage alarm system.
Tyre	275/70R22.5 6pcs
Battery / generator	195A.h×2/150A 28V
Others	Automatic adjustable arm .Gas control system .China ABS, automatic lubrication system.

Body

Body structure	Semi Monocoque
Inner decoration	Forming Soft inner decoration
Door & door pump	Front double inner-swing, rear double inner-swing passenger door ,pneumatic Pump.
Windshield&side window	Whole view laminated front windscreen/ Adhesive side window, sliding side window at rear.
Review system	Rod rear view mirror,Inner Mirror ,Monitoring for down&up.
A/C	30000Kcal/h.Roof mounted .
Heating system/	Water heating defrost system
Video& audio system	MP4 Front & rear 17 color screen
Lamp	Integral Front & Rear combination lamp;
Wiper	Opposite type wiper with detergent
Seats	The plastic seat With soft cushion, standard : 35+1/seats, Multifunction adjustable driver seat .
Handrail	Steel handrail with yellow spray flower.
Floor leather	Anti-slipping Chinese floor leather
Lacquer	China Lacquer
Other	Electric clock, folded sided curtain, driver window sunshade, Steeliness Tyre cover, fire extinguisher(4kg*1), Front.Middle.rear LED electric brand ,Led Inner screen, Vehicle breakdown warning triangles 1pcs, Emergency Hammers 4 pcs, trash basket, 700 elelctric window, inductive fire extinguisher in engine compartment(2 pc)
