Our electric refuse collection truck FT4301 has the following features:
- It is a automatic loading and dump truck
- Elegant shape design with high quality
- Curtis Controller is imported from US manufacturer directly
- High strength PP auto material body and steel frame chassis
- hydraulic dumping system and self collecting system
- sealed type transportation
Application
- Urban road
- different kinds of square
- park
- hospital
- scenic spot
- residential community
- any places needed
Key Components
Item |
Description |
Controller |
Curtis controller, imported from USA directly |
Motor |
Rated power 5.5kw,DC motor Chinese brand |
Battery |
210 ah maintenance-free battery |
Charger |
72V/30A transfered smart charger |
Performance
Item |
Description |
Passenger Capacity |
2 |
Range (unloaded) (km) |
up to 80 |
Max .speed (km/h) |
up to 30 |
Min. turning radius (m) |
5 |
Max. climbing ability(loaded) |
up to 20% |
Max. loading weight (kg) |
1200 |
Dimensions
Item |
Description |
Overall dimensions (mm) |
3730 x 1400 x 2050 (LxWxH) |
Rear garbage box dimensions (mm) |
2250x1350x1200 (LxWxH) |
Min.ground clearance (mm) |
170 |
Wheelbase (mm) |
1950 |
Front wheel tread (mm) |
1200 |
Rear wheel tread (mm) |
1200 |
Body and Frame
Item |
Description |
Frame & Chassis |
Welded steel framework with sand blasting and painting |
Body |
FRP and Plastic |
Roof |
FRP with steel frame, with roof handle |
Windshield |
Laminated glass with wiper |
Roof supports |
Steel |
Seat |
Reborn sponge with artificial leather, high back, with formed armrest |
Rear garbage box |
Steel material, with hydraulic lifting function, side cover and rear door with air-spring |
Floor |
Bamboo floor with Skidproof leather |
Steering Location |
Left hand drive |
Side rear view mirror |
2pcs |
Electric System
Item |
Description |
Lights |
Headlamps, brake & tail lights, turn signals, hazard lights, back-up and dome interior light |
Horn |
Electric horn, |
Reverse buzzer |
Electric, |
Combination switch |
including switch for headlight, turning light, wiper and horn |
DC/DC converter |
48V/12V |
Audio system |
Radio with MP3 receiver and 2 waterproof speaker |
