110V Battery Load Bank is specifically designed for the maintenance of the lead-acid battery discharge in the electricity sector. It is a new high-tech intelligent product that provides safe, reliable and convenient constant testing equipment for the DC system
Product Type:
Different discharge current range
String Voltage |
110VDC |
Discharge current Range |
30A/60A/100A/150A/200A |
All above listed items are standard one. The voltage and currency can be customized according to client’s certain demand. When you place order please indicate the voltage, currency, model and function as well as if you need single section supervision by wire or wireless.
MAIN ACCESSORIES :
Main Functions and Features:
Used to discharge to battery string removed from the system
Discharge to Battery string voltage as 120V, Cell voltage as 1.2V/2V/6V/12V
4 adjustable stop points and multiple alarm designs to control the discharge process intelligently
7inch LCD touch screen for easy operation and showing various parameters real time
Support RS232 real time monitoring by PC or SD Card download data after discharge
PC software for capacity evaluation and report generation
Optional wireless modules for 1.2V/2V/6V/12V cells voltage real-time measuring
On-line monitoring test setting interface:
Online monitoring for battery string: when the battery pack is under the state of online discharge, uniform charge and floating charge, perform real-time online monitoring for all cells. The monitoring includes string voltage, cell voltage, charge/discharge current, monitoring time of battery string, charge/discharge capacity of battery string and etc.
Discharge test setting interface
Providing data management, print, analyze, count report, automatic generate test report. Amplify or minify the voltage curve for easy observation.
The instruments can analyze according to main test function on the histogram and the curve chart. It’s unnecessary to upload the result in PC.
WORKSHOP AND PRODUCTION LINE :
LABORATORY :
PRODUCT TEST :
APPLICATION CASE IN CLIENT'S END :
SHIPPING SERVICE :
