Furniture use available...
Professional design
It is economical, easy to operate.
Reliable and good quality and competitive price
1,high-efficiency powder recycle
2,low energy consumption
3,convenient color change
4,excellent quality
5,competitive price
powder coating booth
High-efficiency powder recycle
low energy consumption
various color
excellent quality Powder Coating booth
Type |
Powder coating booth |
|||
Brand |
King |
|||
Model no. |
PCB-25001(D) |
|||
Production Capacity |
100 SETS PER MONTH |
|||
Voltage/Power |
AS REQUIRED |
|||
Place of Origin |
Shandong, CHINA |
|||
Dimension/Size |
Outer size |
2580mm(L)*3355mm(D)*3040mm(H) |
||
Inner size |
2500mm(L)*2500mm(D)*2200mm(H) |
|||
Structure |
1. Packing down, easy for transport 2. Ground type, staff could go inside for painting powders |
|||
Cabin system/Material |
Made of galvanized steel, powder coated on the surface. |
|||
Powder recovery system |
1.Dust filter cartridge, each size600mm*Φ320mm |
6pcs |
||
2. Solenoid valve, the holeΦ20mm,DC24V |
6pcs |
|||
Circulation system |
1. 1 set of centrifugal blower, motor 7.5KW, air flow 6000~10000m³/h 2. The blower connected with booth by anti-flaming soft tubes 3. The exhaust vent of the blower could be adjusted in four direction |
|||
Blower holder system |
1. Made by 80*80 square tubes 2. Independent from the booth to prevent the resonance and reduce the noise |
|||
Lighting system |
3. 6 SETS of explosion proof lights, two Phillips tubes, total 12pcs,each 36w |
|||
Pulse Programmed control system |
1 set, control the blower, pulse blowback system and lights |
|||
Warranty |
12 MONTHS |
|||
PICTURES FOR THE PRODUCTS powder coating spray booth
powder coating booth
Application: used for the powder coating and line, plant
Shipping: can ship to any port from QINGDAO PORT by sea.
Payment methods: escrow, T/T, L/C
Packing: proper packing suitable for container loading
Services: we supply all equipments about the powder coating, such as booth, oven, reciprocator, gun, line, semi-line and plant; and all the equipments about painting, such as car spray booth, bus/truck spray booth, water curtain paint booth, furniture spray booth, large/industrial spray booth and automatical painting line and so on.
About US
We have more than 20-year experiences on powder coating.
We are a typical Chinese supplier and specialized in the research, development and production of car spray booths, furniture spray booths, industrial spray booth, automatic paint line, powder coating booth, powder coating oven,powder coating gun, powder coating line.
We insist in offering superior quality products and efficient service.
If you are interested in any of our products or would like to discuss a custom order, please feel free to contact us. We are looking forward to forming successful business relationships with new clients around the world in the near future.
