2014 Wholesales CE Industrial Water Cooled Chiller,Water Chiller China Supplier

2014 Wholesales CE Industrial Water Cooled Chiller,Water Chiller China Supplier thumbnail-1
2014 Wholesales CE Industrial Water Cooled Chiller,Water Chiller China Supplier photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
NEW
Type:
Air-Cooled
Place of Origin:
Guangdong, China
Contact Supplier Request Quote Chat Now
Guangzhou Jiayin Machinery Pte., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
GUANGZHOU HUANGPU PORT
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition NEW
Type Air-Cooled
Place of Origin Guangdong, China
Brand Name JIAYIN
Model Number MCA series
Voltage can be changed
Certification CE
Warranty all life
After-sales Service Provided Engineers available to service machinery overseas

Specifications

Industrial Water Chiller:
1Supply water cooled water chiller
2Air cooled water chiller
3Imported compressor water chiller





Water-Cooled Industrial Chiller

          Safety protection system:
          Main power circuit breaker
          Compressor over load protection
          Circulating pump overload protection
          Anti-phase and open phase protection
          High&low pressure protection for refrigerant freezing protection
          Trouble indicator and abnormality buzzer alarm



        Specifications:


Model

MCW-5

MCW-10

MCW-15

CMW-20

MCW-25

MCW-30

MCW-40

Refrigerating capacity

KW

15

29.7

44.1

58.6

69

86.2

117.2



Kcal/h

12900

25600

38000

50390

59340

74100

100790

Input power

  3- phase  380V 50HZ

Compressor

Type

All-closed vorticity/all-closed piston/semi-closed/screw



Input power(kw)

3.75

7.5

11

15

18.75

22.5

30

Built-in freeze water pump

Power(kw)

0.75

1.5

1.5

2.25

2.25

2.25

3.75

Condensor

Type

shelland



Fan Type

1

1.5

1.5

2

2

2

3

Evaporator

type

Stainless steel water tank plate copper tube



Dia of outlet and inlet(INCH)

4× (1/2)

1.5

1.5

2

2

2

3



Water tank capacity(L)

50

120

180

250

300

350

450

Refrigerant

Type

R-22



Flow control

Caloric power expansion valve

Magnetic valve

Castol Italy castol

Filter

ALCO  America ALCO

Electric material

Taiwan Taian technology

Controller

Micro computer digital display control. Degree of precision ±

Temperature range

3ºC------40ºC

Protective device

High/low pressure protective switch, phase failure protection, overload protective switch, antifreeze switch, time delay protection, over-temperature protection, over-current protection

Dimension(cm)

98× 50× 85

162× 60× 136

172× 70× 136

206× 85× 138

220× 85× 138

230× 90× 138

245× 93× 145









Packaging

1.Outside package: Standard export wooden cases
2 .Inner package:Stretch film

2014 Wholesales CE Industrial Water cooled Chiller,Water Chiller China Supplier



Company Information

2014 Wholesales CE Industrial Water cooled Chiller,Water Chiller China Supplier2014 Wholesales CE Industrial Water cooled Chiller,Water Chiller China Supplier



   GuangzhouJiayin Machinery Pte.,Ltd.(Primitive name:Guangzhou Mikasa Machinery Pte., Ltd) is one of the pioneers in auxiliary plastic forming equipment industry in China,specializing in research,design,manufacture and distribution of and service for such equipment with the technology andexperience accumulated about 30 years.

     Our products include crushers,grinders,rubber cutters,dryers,dehumidifiers,suction machines,color mixers,mould temperature controllers,water chillers,color master batch propor.wire recycling machine..more

2014 Wholesales CE Industrial Water cooled Chiller,Water Chiller China Supplier



FAQ

How about the quality of your product?

  • Our products manufactured strictly according to national and international standard.
  • We take a test on every product before delivery.

How about price of this product?

  • We can give the lowest price  than market one.
  • We do quotation  as soon as possible for any customer.
  • Discount  can be given according to quantity.

How about the after-sale service of your company?

  • Our engineer is available to service  machinery overseas.

      •The guarantee period of our product is one year.(except damageable and artificial).
