Home > Products > Blowing Machine > Full automatic 2 lines 2 layers Film Blowing Machine 2016
Full automatic 2 lines 2 layers Film Blowing Machine 2016
- 100 Set / Sets per Month
- China Guangdong Shantou Port
- T/T Credit Card
-
High speed Plastic bottle making 0.5L- 2L 6000BPH Automatic PET bottle blow blowing mold molding machine prices
-
Factory Price High Quality Automatic Fast Plastic PP HDPE Bottle Blowiing Jerrycan Extrusion Blow Molding Machine
-
Semi Automatic PET Plastic Bottle 5 Gallon 20 Liter Blow Molding Machine Price
-
custom design semi-automatic preform pet plastic bottle blowing blow molding machine high speed
-
Semi-automatic Two Cavity Bottle Making Machine Blow Molding Equipment
-
Plastic bottle blowing machine Beverage bottle blowing machine Medicine bottle blowing machine
Product Details
| Condition: | New | Application: | Film | Plastic Processed: | Other, PP, PE, MLLDPE, PA |
| Blow Moulding Type: | Extrusion Blow Moulding | Automatic: | Yes | Place of Origin: | Guangdong, China |
| Brand Name: | Maoxin Machinery | Model Number: | MXSJ SERIES | Voltage: | 380V |
| Power(W): | 180KW | Dimension(L*W*H): | 7.5*5*5.6m | Weight: | 35000kg |
| Certification: | CE ISO | Warranty: | 1 Year | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Features:
* The function of downward blowing and water cooling ensure the excellent transparency of the film.
* The die head structure of multi-layer co-extrusion is reasonble with high precision machining and good product performance.
* The pre-cooling of cooling water ring and the sharp cooling of sizing cover’s overflow water enable the film bubble to be stable, thus distribute the thickness evenly.
* Rotary driving ensures the levelling and regularity of the finished product’s rewinding.
* The line is used for high barrier film production.
* Die head unit can adopt auto die head control.
* Water ring can adopt vacuum sizing control.
* Film is applied in medical, poultry, chemical and high performance packaging material.
Main Technical Parameters:
Model | MXSJ-55-5-1200 |
Suitable material | PP,PE,MLLDPE,PA |
Five layer co-extrusion structure | A/B/C/D/E |
Width of film | 1000mm |
Thickness of film | 0.05~0.20mm |
Max extrusion output | 200kg/h |
Screw diameter | 55mm |
Screw L/D Ratio | 30:1 |
Screw rotation | 20~80r/min |
Power of main motor | 22kwx4 30kwx1 |
Rotary traction form | ±360° rotation |
Total power | 180kw |
Weight of machine | 35T |
Overall Dimension L×W×H | 7.5×5×5.6m |
