Zhenying ZDP Concrete Vibrating Table
Description
ConcreteVibrating Tables are designed to settle and compact dry bulk materials in various types of containers. Their application provides either a sizeable increase in the net weight of the container or reducing in the container size with subsequent savings in shipping and storage space.
The choice of the proper type and model depends upon the application, characteristics of the material or objects being handled, its reaction to vibration, the maximum weight to be handled and the type of container.
Feature
1 Vibration motor as vibration source, low noise, low power consumption and easy maintenance.
2. Simple structure, reliable function, light weight, small size, easy to install.
3 .highpower, large table; maximum power of 7.5kw, exciting force 80KN, can carry the weight
of the sand box 8T.
4 .Adjustable height table, suitable for pipeline use.
5 .Install the vibration of the motor by adjusting the position of threedimensional vibration
can be achieved for complex casting cavity.
6.In styling process, without harm to the model, for best compaction results.
7. By increasing the positioning device can ensure accurate positioning in the production line
Applications
ZDP series vibrating table can be widely used in metallury,mould,food,Chemical and Building material etc.
Technical Parameter
Model |
Aera(square meter) |
Powder(kw) |
Amplitude(mm) |
Weight(kg) |
ZYD-ZDP-500×500 |
0.25 |
2×0.25 |
2-5 |
300 |
ZYD-ZDP -1000×1000 |
1 |
2×0.4 |
2-5 |
600 |
ZYD-ZDP -1200×1200 |
1.44 |
2×3 |
2-5 |
1200 |
ZYD-ZDP -1500×1500 |
2.25 |
2×3 |
2-5 |
2000 |
ZYD-ZDP -3000×3000 |
9 |
6×1.5 |
2-5 |
3000 |
Concrete Vibrating Table's Packing & shipping
About us:
Other products:
Our servicce:
1.Installation,Debugging.
Provide installation files, technical data and related soft copies or videos etc to ensure customer could install and debug by themselves.
2.warranty
The provider guarantee the vibrating screen could meet production technical standard and performance requirements indicated in the contract, 24 months for the machine after delivery ,12 months for the motor after delivery.
3.Technical Support
Our company will make occasional call to find problems and solve them in time.Provide technical support timely.
4.Response Time(24 hours)
Contact us through Telephone or Email, we will respond within 24 hours.
