Zhenying Brand Vibrating Grizzly Feeder Price Quality Choice

Zhenying Brand Vibrating Grizzly Feeder Price Quality Choice thumbnail-1
Zhenying Brand Vibrating Grizzly Feeder Price Quality Choice photo-1
US$ 399 - 100,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Application:
Powder/Sand/Particle/Granule,Stone/Sand/Powder
Power Type:
Electric
Contact Supplier Request Quote Chat Now
Xinxiang Zhenying Mechanical Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao/Shanghai/Tianjin or as you require
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Application Powder/Sand/Particle/Granule,Stone/Sand/Powder
Power Type Electric
Capacity(t/h) 25-400Tons/hr
Place of Origin Henan, China
Brand Name Zhenying
Model Number ZYF
Power(W) 1.1x2-22kw
Dimension(L*W*H) 800*2800*900mm
Weight 1050-8200kg
Certification ISO9001:2008 & SGS
Warranty 13 months
After-sales Service Provided Engineers available to service machinery overseas

 Zhenying brand vibrating grizzly feeder price

Zhenying brand vibrating grizzly feeder price



Zhenying machine,Xinxiang is the professional machinery manufacturer specially in sieving,conveying,crushing and feeding equipment.



High quality product and service,hard-woking and cooperative spirits accelerate the growth of Zhenying.



With ISO9001:2008,CE Certificate,AAA credit company and many other government credits, our products are your best choice.



Zhenying means flying eagle in Chinese,hope we can fly far away in the sky of world machinery sky.





Zhenying brand vibrating grizzly feeder
Product
Feature :



♥ Aadopts linear vibrating feeding and the whole-base structure.

♥ Control the vibrating strength ,Through the stepless adjustment the

angle of eccentric block

♥ Conveniently amount feeding,steadyvibrating, reliable working, flexible adjustment,

easy installment.

♥ Efficient for reducing the working cost and the pressure of workers and perfect

machine for continual and uniform feeder for stone crusher.

♥ Offer machine on the base of the result from our test basis,feedback from our clients,

and the research from our R&D,

♥ Have more than160 excellent and diligent workers and based on the advanced equipment

♥ Have many high quality installers: they are ready to serve you all the time.

OEM service : Availale
Installation service : ♥ We can supply the professional installation technician and workers;

♥ We have more than 300 technician and workers ready to install the machines for you;
♥ We can supply the professional training and even we can arrange workers to help you operate the motor vibrating feeder.
Specifications:

♥ Raw material

♥ Feeding size

♥  Capacity(Kg/hr)
Price
payment: L/C,T/T,Western Union,Escrow
Packing Free fumigation wooden cases , export standards
Port: Shanghai,qingdao,Tianjin
MOQ: 1 set
Contact us
Skype:  cnzymachinery007
QQ:   783297712
Mob: 86 18737382780
Tel: 86-373-5031958
Fax:

86-0373-3532216
Add:

No.1018,South Xinfei road,Xinxiang,Henan,China

 Product Image

 Zhenying brand vibrating grizzly feeder price



 Vibrating Grizzly Feeder



 Zhenying brand vibrating grizzly feeder price



Vibrating Feeder Introduction:



Electromagnetic Vibrating Feeder is widely used in industries of metallurgy, mining, coal, building meterials, chemical, electric power, foodstuffs, machinery and etc. It can feed bulk shape material, granular material, and power material from storage silo or funnel uniformly, continuously and quantificationaly to various receiving equipments, such as belt conveyor, bucket elevator, screening equipment, crusher, grinder, etc. And also it can be used in the automatic system, and where feeding accuracy requirement is high.

Zhenying brand vibrating grizzly feeder price



Working Principle:



 When the power is on, the electric current passes the electric coils, which creates a magnetic field. The magnetic force changes into vibrating force, which forces the transmission trough body to make simple harmonic vibration or similar to simple harmonic vibration in a certain direction. When the acceleration of its vibration achieves some certain value, the materials will make continuous and small throws or slides along the transmission direction in the transmission trough body, which causes the forward motion and transmission of the materials.







Tech Parameter





Model No.

Feeding capacity (t/h)

Max. feeding size
(mm)

Double amplitude (mm)

Voltage (V)

Electric current
(A)

Power
(kw)

Weight
(kg)

Level angle

-10° angle

FZ-1

5

7

50

1.75

220

1.34

0.06

75

FZ-2

10

20

50

3

0.15

146

FZ-3

25

35

75

4.6

0.2

217

FZ -4

50

70

100

8.4

0.45

412

FZ -5

100

140

150

12.7

0.65

656

FZ -6

150

210

200

1.5

380

16.4

1.5

1252

FZ -7

250

350

250

24.6

3

1920

FZ -8

400

560

300

39.4

4

3040

FZ -9

600

840

350

47.6

5.5

3750

FZ -10

750

1050

500

39.2*2

4*2

6491

FZ -11

1000

1400

500

47.6*2

5.5*2

7680







Vibrating feeder Factory



Zhenying brand vibrating grizzly feeder price

Zhenying brand vibrating grizzly feeder price



Customer's using site



Zhenying brand vibrating grizzly feeder price

 Zhenying brand vibrating grizzly feeder price

 Zhenying brand vibrating grizzly feeder price I nquiry ,the detail information and competitive cost will be sent.

 Avy Zhang



Add:No.1018 South of Xinfei Road, Xinxiang, Henan



Tel: 0086-0373-5031958, 3532216(24 hours online for you)



Mob:8618737382780



Skype:cnzymachinery007



QQ:2820720356



Fax:0086-0373-3532216



Web Site:





 Zhenying brand vibrating grizzly feeder price

Zhenying brand vibrating grizzly feeder price
