DY reversible high inclination angle hopper belt conveyor is suitable for harbor, mine, grain, freight yard, warehouse and other departments, which is a kind of simple transitions, wide application, and high efficiency transportation equipment.
DY belt conveyor machine is a kind of equipent mainly used for engineering project.
DY mobile and flexible pvc belt conveyor machine is easy to move, and mainly used for the occasion where the loading place is changeable easily,for eg.port, yard, coal spot, garage,
construsion sit and sandstone spot or agriculture spot.
DY reversible high inclination angle hopper belt conveyor's reducer motor.
DY reversible high inclination angle hopper belt conveyor's roller.
DY belt conveyor machine usually used for short distance transporation and bulk materials as well as materials in article less than 100 KG.
There are two types fot the pvc belt conveyor machine :1.able to be lifted up 2.unable to be lifted up. There are two forms of wheel, one gas wheel, the other steel wheel.
The angle can be ajusted for the machine body over 10m.
conveying length |
10m |
15m |
Conveyor width |
500-800(mm) |
0.6 |
Conveyor speed |
0.8~1.6m/s |
2000 |
Conveying capacity(V=1.0m/s) |
70~278m³/h |
321 |
Rack adjustment angle |
9°~20° |
9°~20° |
Conveying max height |
391mm |
5700mm |
Conveying min height |
2000mm |
2700mm |
Taut route |
300mm |
300mm |
Motor power |
2.2kw-5.5kw |
2.2kw-5.5kw |
Transmission reduction ratio |
16.6 |
16.6 |
Steel cable 12-6×19 |
17m |
26m |
Belt 4(3+1.5) |
22m |
31.8m |
DY reversible high inclination angle hopper belt conveyor can be designed according to your width and length.
How to choose the hopper belt converor machine ?
1.Which products you want to transfer ?
2.How about the height and length you want ?
3.What's your capacity(kg/h) ?
4.Which materials you choose ?fully carbon steel,fully stainless stee or
the contacting part stainless steel,others carbon steel .
5.Could you kindly tell us your voltage in your country ??
6.You can tell us your special design on the belt conveyor,
we will design the drawing for you .
We are the manufacturer ,welcome you come to our company and factory !
