Storage Battery Inverter

US$ 1,000 - 5,000 MOQ: 10 Sets

Key Specifications

Place of Origin:

Shandong, China

Brand Name:

BOS

Model Number:

SX20KS

Shandong BOS Energy Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Shandong, China

Brand Name BOS

Model Number SX20KS

Specification Normal

Application Home

Output Voltage (V) 380Vac

Load Power (W) 10KVA

Solar Power (W) 10KVA

Work Time (h) 12h

Specifications

storage battery inverter
1.DC/AC AC/DC
ntrol the battery charging and discharging
3.grid tie and grid off

storage battery inverter features:

1.Bi-grid inverter can not only convert the DC power into AC power,but also can invert the AC power to DC power.

2.Bi-grid inverter mainly control the battery’s charging and discharging,at same time it is the core control equipment.

Type	SX10KS		SX20KS	SX50KS	SX100KS				SX250KS
Rated capacity	10kW		20kW	50 kW	100 kW				250kW
Overload	11kW		22 kW	55 kW	110 kW				275kW
Rated grid voltage		380 Vac
Grid voltage range		310~450Vac
Grid frequency		50Hz/60Hz
Total harmonic distortion(THD)		<3%
Power factor		≥0.99
Rated output voltage		380 Vac
Output voltage accuracy		<3%
Output frequency		50Hz/60Hz
Output overvoltage		>450 Vac
Output under-voltage		<310 Vac
Max DC power	11kW		22 kW	55 kW	110 kW			275kW
DC voltage range	450-750Vdc
Max DC current	25A		50A	122A	244A		611A
DC current ripple	<5%
Max efficiency	96.6%
Temperature	-25~+60°C
Humidity	0~95%,non condensing
Noise	<50dB
Protection	Polarity inverse,short circuit,island efficiency.overheat,overload.ground fault protection
Cooling method	Forced cooling
Protect degree	IP20
Indication	Touching screen
Communication	RS485(MODBUS protocol)
W×D×H(mm)	5805151250		6506101560	8006002060	10008002060	20008002060
Weight (kg)	150		300	700	900	1300
