solar on grid inverter 3kw
1.No transformer designing,small size,light weight
2.Machine efficiency>98.7%,reduce the system investment
3.Advanced technology for maximum power point tracking(MPPT)
4.MPPT efficiency>99%
5.Wide input voltage range
6.High reliability due to complete protection function
7.Installation and operation simplely
Type |
BNSG3KTL |
BNSG5KTL |
Max. DC input power |
3.6KWp |
6KWp |
Max. DC input voltage |
780Vdc |
|
Max.PV voltage range(MPPT) |
350Vdc~600Vdc |
|
Most input approach |
3 approaches |
|
Max. Input current |
11A |
17A |
Nominal AC output power |
3KW |
5KW |
Max. AC output power |
3.6KW |
6KW |
THD of AC current |
<4%(nominal power) |
|
Power factor |
>0.99 |
|
Max. Efficiency |
97% |
|
Euro efficiency |
96% |
|
Nominal AC voltage |
190VAC~250VAC |
|
Nominal AC frequency |
50Hz/60Hz |
|
Internal power consumption an night |
<10W |
|
Automatically put into operation conditions |
When the DC input and power grids meet to the requirements, the inverters automated operation |
|
Automatic restart time |
5min(time adjustable) |
|
Protection |
Possess the protecting function of polarity connecting contrary, short circuit, island effects, over heat, over land |
|
Comm. interfaces |
RS485 |
|
Operating Temp. |
-20°C~+40°C |
|
Relative humidity |
0~95%,no condensing |
|
Altitude(m) |
≤2000meters(Over 2000 meters to reduce the using amount) |
|
Cooling method |
Controlled forced-air cool |
|
Noise |
≤60dB |
|
Protection degree |
IP20(indoor) |
|
Size(W*L*H mm) |
466*393*195 |
|
Weight(kg) |
20 |
|
