Specifications
coffee sleeve folder gluerSFG model automatic folder gluer machine belongs to economic type product, with broad usage an
coffee sleeve folder gluer
SFG model automatic folder gluer machine belongs to economic type product, with broad usage and flexible debug.It can paste various boxes, such as the medicine box cosmetics box and the samller box such as match boxes etc.The min widest can make 70MM open size of the boxes.
Major technical index
SHH-800(wide belt)
Model | (Amax) | (Amin) | (Bmax) | (Bmin) | (Cmin) | (Dmin) | (Fmin) |
SHH-800 | 700mm | 70mm | 520mm | 110mm | 8mm | 70mm | 51mm |
SFG-1200(wide belt)
Model | (Amax) | (Amin) | (Bmax) | (Bmin) | (Cmin) | (Dmin) | (Fmin) |
SHH-1200 | 700mm | 70mm | 790mm | 110mm | 8mm | 70mm | 51mm |
SFG-800(narrow belt)
Model | (Amax) | (Amin) | (Bmax) | (Bmin) | (Cmin) | (Dmin) | (Fmin) |
SHH-800 | 700mm | 70mm | 520mm | 70mm | 8mm | 70mm | 35mm |
Characteristics
Linear velocity | 0~200m/min |
Suitable paper quality | 220~800g/m2 cardpaper |
Paste box basic form | One-side edge pastes, two-side edge pastes. |
Feeding way | Automatically and continuously feeding |
Adhesive | Solute type |
Needed power | AC220V 3.5KW |
Weight | 1500KG |
Overall Size | 5300mmx820(1250)mmx1300mm |
The scope of Count | 0~999999 |
