Help CenterScrew Plastic Auger/feeder
US$ 800 - 2,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Screw Conveyor
Material:
Stainless Steel
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Plastic Vertical Dryer 1000KG/2000KG /3000KGUS$ 4,000 - 25,000MOQ: 1 Set -
PVC Laboratory Mixer Unit/Hot and Cold MixerUS$ 1,200 - 10,000MOQ: 1 Set
-
Automatic Screw Feeding Machine/equipment for Sugar/powder/granulesUS$ 800 - 2,000MOQ: 1 Set
-
Automatic Flexible Auger Conveyor for PvcUS$ 800 - 2,000MOQ: 1 Set
-
Automatic Flexible Auger Pvc Powder ConveyorUS$ 800 - 2,000MOQ: 1 Set
Condition
New
Type
Screw Conveyor
Material
Stainless Steel
Material Feature
Heat Resistant
Structure
Conveyor System
Load Capacity
100
Place of Origin
Jiangsu, China
Brand Name
BE
Model Number
ZJF-700 Automatic Powder Feeder for pvc
Voltage
220V-600V
Power(W)
2.2KW
Dimension(L*W*H)
According customer required
Certification
CE ISO
After-sales Service Provided
Engineers available to service machinery overseas
ZJF-700 Automatic Powder Feeder
Model |
ZJF-600 |
ZJF-1000 |
ZJF-2000 |
ZJF-3000 |
Power(KW) |
0.75 |
1.1 |
1.5 |
1.5 |
Pipe Diameter(mm) |
76 |
102 |
120 |
140 |
Capacity(kg/h) |
600 |
1000 |
2000 |
3000 |
Size(cm) |
65*65*80 |
100*75*80* |
120*80*80 |
160*80*80 |
Weight(kg) |
80 |
150 |
200 |
300 |
Purpose and Scope:
The DTC series screw feeder to plastic processing machinery required ancillary equipment, a net powdered or granulated plastic materials automatically transported into the hopper, adjust the mixer device. Contact material made of stainless steel, raw materials during transport is completely free from contamination, do not bring any foreign objects, enabling the production process to achieve full closure automation.
Easy to install, and can be moved, such as multiple Banliao use the same material, just a platform feeder for feeding simultaneously multiple spices machines, eliminating the hassle of artificial feeding is feeding safer work , more time and more effort.
The main technical parameters:
| Model Specification | Unit | ZD-600 | ZD-1000 | ZD-2000 | ZD-3000 |
| Power supply | V | 380V50Hz | 380V50Hz | 380V50Hz | 380V50Hz |
| Feeding motor power | KW | 0.75 | 1.1 | 1.5 | 1.5 |
| Pusher motor power | KW | 0.75 | 0.75 | 1.75 | |
| Feeding tube diameter | mm | 76 | 102 | 120 | 140 |
| Feeding height | m | 3 | 3 | 3 | 3 |
| The feeding amount | kg/H | 600 | 1000 | 2000 | 3000 |
| Hopper capacity | kg | 80 | 150 | 200 | 250 |
| Box Size(L×W×H) | cm | 65×65×80 | 100×75×80 | 120×80×80 | 160×80×80 |
| Weight | kg | 80 | 150 | 200 | 300 |
