screw loader for material
1. Working Principle
ZD series screw-driver feeder adopts one screw for feeding. Once the Power switch is opened, the screw begins to rotate and feed, so that material can be lifted up to the material outlet. The machine will stop working automatically when the level-sensing the device indicates that material is full, and starts working again after several minutes later when the material level decreases. (The delay time is depended on your choice)
2. Main Technical Parameters
Model NO. |
ZD-600 |
ZD-1000 |
ZD-2000 |
ZD-3000 |
Power (V) |
380V 50HZ |
|||
Motor Power (kw) |
0.75 |
1.1 |
1.5 |
1.5 |
Diameter of feeding pipe (mm) |
89 |
108 |
120 |
140 |
Feeding height (m) | ||||
Feeding capacity (kg/h) |
600 |
1000 |
2000 |
3000 |
Volume of feed box (L) |
100 |
200 |
250 |
300 |
Size of feed box (L*W*H) (mm) |
650*650*800 |
100*750*800 |
1200*800*800 |
1600*800*800 |
Weight (kg) |
80 |
150 |
200 |
300 |
