LED Large TV Outdoors

Name: LED Large TV Outdoors
Brand: Shenzhen CCY
SKU: 106813565

US$ 800 - 2,000 MOQ: 1 Square Meter

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

Shenzhen CCY

Model Number:

P20 outdoor full color

Shenzhen CreKing Electronics Technology Co., Ltd.

6Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name Shenzhen CCY

Model Number P20 outdoor full color

Usage Outdoor

Tube Chip Color Full Color

Display Function Video

Pixels 20mm

Specifications

LED large TV outdoor RGB P20
1) wide viewing angle
2) high brightness
3) low power and voltage
4) good after-sales services

Iterm	PH20mm Outdoor
Pixel pitch	20mm
LED configuaration	2R1G1B
Real Density of pixel	2500dots/sqm
Virtual Density of pixel	10000dots/sqm
Module resolution	16dots*8dots
Module size	320mm*160mm
Cabinet size	Adjustable(big/small)
Refresh frame frequency	≥400HZ/s
Bestviewing distance	20-140m
Viewing angle/horizontal	110°
Viewing angle/vertical	50°
Max consumption	750W/Sqm
Average consumption	360W/Sqm
Gray scale/display color	256/display 16.7M
Waterproof	IP65
Driving IC	constant current
Brightness	≥5500nits
Brightness adjustment	Manual R.G.B each color 256, automatic 8 grades are adjustable
Input signal	RF,S-Video,RGB,RGBHV,YUV,YC,COMPOSITONS
Control system	PCTV card(optional)+DVI card+master control card+optical transmitter(optional)
Date transmission	Unshielded twisted pair net cable transmission distance 100m, Fiber optic transmission 15km
System operation platform	Windows98/me/2000/NT/XP
Life span	≥10000hrs
Malfunction do rate	<0.0001
Earth leakage current	<0.1mA
Working temperature& humidity	`0°C-45°C,10%-95%

LED large TV outdoor RGB P20
