Full Color Outdoor Curtain Led Display Board P31.25

Full Color Outdoor Curtain Led Display Board P31.25 photo-1
US$ 1,000 - 1,705.88 MOQ: 1 Square Meter
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
CCY
Model Number:
outdoor curtain led display board P31.25
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen Hongkong
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Guangdong, China
Brand Name CCY
Model Number outdoor curtain led display board P31.25
Usage Outdoor
Tube Chip Color Full Color
Display Function Video
Pixels Other, 31.25

Specifications

We have 10 years' experience in led display board industry, we packing the led chip ourselves. Our team provide good service

full color outdoor curtain led display board P31.25

2. led display board module specification

No.

Item

Parameter

1

Pixel Pitch

31.25mm

2

Pixel Density

1024 Dot/m²

4

LED configuration

(1R1G1B)

5

Module Dimension

500mm*500mm*60mm

6

Module pixel

16dots*16dots

7

Driver voltage

DC5V

2.3 Screen body specification

No.

Item

Technique Parameter

1

Cabinet Pixel

16 dots(L)*16 dots(H)=256 dots

2

Number of cabinet

   pcs

3

Screen body area

   sqm

4

Led driver/scan mode

Static constant current driver

5

Best viewing distance

25M-300M

6

Grey scale

Red,Green,Blue, per 4096grade

7

Brightness

3000-4000cd/m2

8

Viewing angle

Horizontal:1200º/Vertical:60º

9

Exchange frame speed

60HZ

10

refresh frame frequency

≥600HZ

12

Average power consumption

75W/m2

13

Life span

≥100,000 hours

14

Blind spot rate

1/100000(Disperse distributing)

15

Working environment

-20 ~50 Degrees Celsius

16

Operating voltage

AC220V OR 110V, ±10%,50Hz

17

Screen body weight

4kg/pcs

18

MTBF

≥10,000 Hours

19

Intension of resisting electricity

50HZ/1500V /1min

20

Temperature

Metal≤40K, Insulation≤65K

21

Input signal

S-Video;VGA;RGB;Composite Video;SDI etc.

22

Control mode

WIN,XP PC+ control software and hardware+ display software and hardware
