SMD Full-color 3 In1 Indoor Screen(PH6)
US$ 500 - 1,500
MOQ: 1 Cubic Meter
Key Specifications
Get Latest Price
Place of Origin:
Hunan, China
Brand Name:
MHG
Model Number:
PH6
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen or guangzhou port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Double Color PH16 Led DisplayUS$ 1,000 - 1,500MOQ: 1 Cubic Meter -
Moving Head Light(M-YL2)US$ 200 - 1,000MOQ: 10 Cubic Meters
-
Led Cube Display -p4.5 mmUS$ 1,000 - 7,800MOQ: 1 Piece
-
PH8 Indoor LED Display SMD 3 in 1US$ 800 - 1,500MOQ: 10 Square Meters
-
Indoor PH16 Mesh Screen SMD 3 in 1US$ 500 - 600MOQ: 10 Square Meters
Place of Origin
Hunan, China
Brand Name
MHG
Model Number
PH6
Usage
Outdoor
Tube Chip Color
Full Color
Display Function
Video
Pixels
Other, 6mm
Screen Dimension
Customized Size
Established in 2003, the member of China Entertainment Association,is a professional manufacturer of LED display,stage lighting. All of our products passed the ISO9001:2000 ,3C,CE,FCC,ROHS,LVD ...certifications .
MHG PH6 Indoor full color LED Display (SMD 3-in-1)
1.Measured by the China ETA Quality Inspection:It is able to work between -40 °C to +65 °C (IP65)
2.This modle Widely used in advertising, sports,finances, post offices, telecom, commerce, hospitals, sports stadiums,airports and railwaysand other public places until now.
Specifications:
| LED DISPLAY TYPE | PH6 SMD FULL 3 in 1COLOR SERIES (INDOOR) | ||
| Pixel pitch | 6mm | Frame frequency | 60-85HZ |
| Physical density | 27777pixels/sq | Refresh rate | 240-1000HZ |
| LED configuration | SMD 3 in 1 | Brightnessd adjustment | 0-100% 8 levels automatic |
| Physical density | 1R1G1B | Gamma correction | -5.0-5.0 |
| Module size | 192*96mm | Correction scale level | 16bits |
| Module resolution | 32*16 | Color temperature | 5000-9300k |
| Drive mode | Dynamic 1/8 duty ty constant current |
Brightness correction | Pixel,module, cabinet correction |
| Brightness | ≥2000cd/m2 | Contrast | ≥2000:1 |
| Control distance | UTP CAT5E:100m,muti-mode fiber:500m single-mode fiber:10km |
Input source support | composite,S-video,component, VGA,DVI,HDMI,SDI,HD SDI |
| View angle | 140./140. | Operating temperature | -40-60.C |
| Minimum view distance | 6m | Operating humidity | 10-90% RH |
| Grey scale | 10bits/1024 levels | Operating life span | 100,000 Hours |
| Color capacity | 1.07 billion | MTBF | 5000 hours |
| Maximum power consumption | 1380w/ M2 | Protection ratings | IP31 |
| Ave power consumption | 460w/M2 | Out of control rate | 0.01% |
| Operationg power source | AC90-260V 50-60 HZ | ||
MHG LED DISPLAY SMT WORKSHOP:
product picture:
