Help CenterSMD Full-Color 3 in 1 LED Display
US$ 500 - 800
MOQ: 1 Square Meter
Key Specifications
Get Latest Price
Place of Origin:
Hunan, China
Brand Name:
MHG
Model Number:
SMD Full-Color 3 in 1
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen or guangzhou port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
P5 High Definition Video Led ScreenUS$ 500 - 5,000MOQ: 1 Square Meter -
PH16 Mesh Screen IndoorUS$ 500 - 600MOQ: 10 Square Meters
-
Single Color RED Led Screen(PH16)US$ 500 - 1,500MOQ: 1 Cubic Meter
-
Single Color RED Led DisplayUS$ 500 - 1,000MOQ: 1 Cubic Meter
-
DIP Full-color /outdoor Led Display(P14)US$ 1,000 - 2,000MOQ: 1 Cubic Meter
Place of Origin
Hunan, China
Brand Name
MHG
Model Number
SMD Full-Color 3 in 1
Usage
Indoor
Tube Chip Color
Full Color
Display Function
Video
Pixels
Other, 4mm & 5mm & 6mm & 7.62mm
Screen Dimension
Customized Size
Established in 2003, the member of China Entertainment Association,is a professional manufacturer of LED display,stage lighting. All of our products passed the ISO9001:2000 ,3C,CE,FCC,ROHS,LVD ...certifications .
|
Item |
PH4 | PH5 | PH6 | PH7.62 | ||
| Module Parameters | Physical Pitch | 4mm | 5mm | 6mm | 7.62mm | |
| Physical Density | 62500pixels/m2 | 40000pixels/m2 | 27777pixels/m2 | 17222pixels/m2 | ||
| LED Shape & Size | SMD 3 in 1 | SMD 3 in 1 | SMD 3 in 1 | SMD 3 in 1 | ||
| LED Arrangement | 1R1G1B | 1R1G1B | 1R1G1B | 1R1G1B | ||
| Module Size | 128×128mm | 160×160mm | 192×96mm | 244×122mm | ||
| Module Resolution | 32×32 | 32×32 | 32×16 | 32×16 | ||
| Drive Mode | Dynamic 1/8 Duty Constant Current | Dynamic 1/8 Duty Constant Current | Dynamic 1/8 Duty Constant Current | Dynamic 1/8 Duty Constant Current | ||
| Display Parameters | Optical | Brightness | ≥2500cd/m2 | ≥2000cd/m2 | ≥2000cd/m2 | ≥1500cd/m2 |
| Contrast | ≥2000:1 | ≥2000:1 | ≥2000:1 | ≥2000:1 | ||
| View Angle, 50% Brightness | 140°/140° | 140°/140° | 140°/140° | 140°/140° | ||
| Minimum View Distance | 4m | 5m | 6m | 8m | ||
| Grey Scale | 10bits/1024levels | |||||
| Color Capacity | 1.07billion | |||||
| Power | Maximum Power Consumption | 3100W/m2 | 2000W/m2 | 1380W/m2 | 860W/m2 | |
| Ave. Power Consumption | 1000W/m2 | 650W/m2 | 460W/m2 | 280W/ | ||
| Operating Power Source | AC90-260V 50-60Hz | |||||
| Controller | Frame Frequency | 60-85Hz | ||||
| Refresh Rate | 240-1000Hz | |||||
| Brightness Adjustment | 0-100% 8 levels automatic | |||||
| Gamma Correction | (-5.0-5.0) | |||||
| Correction Scale Level | 16bits | |||||
| Color Temperature | 5000-9300K | |||||
| Brightness Correction | Pixel, Module, Cabinet Correction | |||||
| Input Source Support | Composite, S-Video, Component, VGA, DVI, HDMI, SDI, HD_SDI | |||||
| Control Distance | UTP CAT5E: 100m; Multi-mode Fiber: 500m; Single-mode Fiber: 10km | |||||
| Reliability | Operating Temperature | (-40oC~+65oC) | ||||
| Operating Humidity | 10-90% RH | |||||
| Operating Life Span | 100,000 Hours | |||||
| MTBF | 5,000 Hours | |||||
| Protection Ratings | IP31 | |||||
| Out of Control Rate | 0.01% | |||||
