White Healthy 65-800mm UHMWPE Pipe Suppliers Used in Food Industry Quality Choice
US$ 2 - 200
MOQ: 1 Meter
Key Specifications
Get Latest Price
Place of Origin:
Henan, China
Brand Name:
Max
Model Number:
UHMWPE Pipe
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
China Supplier 1.0Mpa UHMWPE Pipe for Copper Mine SlurryUS$ 2 - 200MOQ: 1 Meter -
Large Diameter Plastic UHMWPE Pipeline for DischargingUS$ 2 - 200MOQ: 1 Meter
-
High Quality Best Price 65-800mm UHMWPE Pipeline for Coal SlurryUS$ 2 - 200MOQ: 1 Meter
-
Abrasion Resistant Plastic 400mm UHMWPE Pipe for Coal SlurryUS$ 2 - 200MOQ: 1 Meter
-
New Plastic Products 219mm UHMWPE Tubing for TailingUS$ 2 - 200MOQ: 1 Meter
Place of Origin
Henan, China
Brand Name
Max
Model Number
UHMWPE Pipe
Material
Other, UHMWPE Powder
Specification
65mm-800mm
Length
6m,12m or as request
Thickness
8mm-38mm
Standard
GB Standard
White Healthy 65-800mm UHMWPE Pipe Suppliers Used in Food Industry
What is UHMWPE Pipe
Ultra-high molecular weight polyethylene (UHMWPE) is a kind of engineering thermoplastics with more than 2 million viscosity-average molecular weight, under the polymerization of ethylene, butadiene monomer in the catalyst.
UHMW slurry pipe features:
1. Anti-abrasion:the abrasion value of UHMWPE pipe is 1/4 of steel pipe,1/3 of HDPE pipe under same working condition.
2. Water hammer resistance:UHMWPE pipes have strong enduring capability to the impacts from various sands,mud and slurries.
3. Corrosive resistance:With higher structure stability ,UHMWPE pipes are corrosive resistant to sea waters.No electro chemical corrosion,no need anti-corrosive coating.
4. Self-lubrication:The roughness of UHMWPE pipe is 0.00022mm.The pressure loss of UHMWPE pipe is 1/10 of steel pipes ,1/7 of nylon pipes.Over 20% of transfer efficiency will be increased.
5. Non-scaling:The internal wall is very smooth,preventing the fouling on the wall and no influence to the production efficiency.
6. Light weight:The density of UHMWPE pipe is only 1/8 of steel pipe.It is easy to move and install,especially suitable for the working sites at he lifting machines could not work.
7. Easy connection:flanges are available to connect the pipes,no need washers .The installation will be very easy and fast.
8. Anti-aging:the UHMWPE pipes will not be aging in 50 years under hot sunlight,and it could work over 100 years if buried underground.
9. Environment friendly: UHMWPE pipe is nontoxic,no bacteria,and no pollution to environment.
10. Low carbon:the discharge of carbon dioxide during UHMWPE pipe production is only 15% of steel pipe production.
1. Anti-abrasion:the abrasion value of UHMWPE pipe is 1/4 of steel pipe,1/3 of HDPE pipe under same working condition.
2. Water hammer resistance:UHMWPE pipes have strong enduring capability to the impacts from various sands,mud and slurries.
3. Corrosive resistance:With higher structure stability ,UHMWPE pipes are corrosive resistant to sea waters.No electro chemical corrosion,no need anti-corrosive coating.
4. Self-lubrication:The roughness of UHMWPE pipe is 0.00022mm.The pressure loss of UHMWPE pipe is 1/10 of steel pipes ,1/7 of nylon pipes.Over 20% of transfer efficiency will be increased.
5. Non-scaling:The internal wall is very smooth,preventing the fouling on the wall and no influence to the production efficiency.
6. Light weight:The density of UHMWPE pipe is only 1/8 of steel pipe.It is easy to move and install,especially suitable for the working sites at he lifting machines could not work.
7. Easy connection:flanges are available to connect the pipes,no need washers .The installation will be very easy and fast.
8. Anti-aging:the UHMWPE pipes will not be aging in 50 years under hot sunlight,and it could work over 100 years if buried underground.
9. Environment friendly: UHMWPE pipe is nontoxic,no bacteria,and no pollution to environment.
10. Low carbon:the discharge of carbon dioxide during UHMWPE pipe production is only 15% of steel pipe production.
Application Areas of UHMWPE Pipe
it is widely used in dredging, water supply, metallurgical mines, electric power, petroleum, natural gas, textiles, paper making, food, chemical industry, machinery, etc.
The UHMWPE PIPE specification:
Diameter (MM) |
0.6Mpa |
0.8Mpa |
1.0Mpa |
1.25Mpa |
1.6Mpa |
2.0Mpa |
Thick(MM) |
Thick(MM) |
Thick(MM) |
Thick(MM) |
Thick(MM) |
Thick(MM) |
|
65 |
|
|
|
|
8 |
9 |
96 |
|
|
|
|
9 |
10 |
110 |
|
|
|
|
8 |
10 |
130 |
|
|
|
8 |
10 |
12 |
159 |
|
|
|
10 |
12 |
15 |
168 |
|
|
8 |
10 |
13 |
16 |
205 |
|
8 |
10 |
12 |
15 |
18 |
219 |
|
9 |
11 |
13 |
16 |
20 |
236 |
|
10 |
12 |
14 |
18 |
22 |
250 |
|
10 |
12 |
15 |
19 |
23 |
273 |
9 |
11 |
13 |
16 |
21 |
25 |
280 |
9 |
11 |
14 |
17 |
21 |
26 |
300 |
10 |
12 |
15 |
18 |
23 |
27 |
315 |
10 |
12 |
15 |
19 |
24 |
29 |
325 |
10 |
13 |
16 |
19 |
24 |
30 |
350 |
11 |
14 |
17 |
21 |
26 |
32 |
377 |
12 |
15 |
18 |
22 |
28 |
35 |
400 |
12 |
16 |
19 |
24 |
30 |
36 |
415 |
13 |
16 |
20 |
25 |
31 |
|
426 |
13 |
17 |
20 |
25 |
32 |
|
536 |
16 |
21 |
26 |
23 |
|
|
560 |
16 |
22 |
27 |
33 |
|
|
630 |
19 |
25 |
30 |
37 |
|
|
652 |
20 |
26 |
32 |
38 |
|
|
710 |
21 |
27 |
34 |
|
|
|
800 |
23 |
31 |
38 |
|
|
