HDPE Pipe Socket Welding Machine
US$ 0.8 - 88
MOQ: 1 Carton
Key Specifications
Get Latest Price
Place of Origin:
Henan, China
Brand Name:
MAX, MAX
Model Number:
HDPE100
Payment & Shipping
Payment Methods:
Port of Shipment:
QINGDAO TIANJIN SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
HDPE Pipe Fitting Butt Welding Machine For HDPE PipesUS$ 0.8 - 88MOQ: 1 Carton -
HDPE Pipe Butt Fusion MachineUS$ 0.8 - 88MOQ: 1 Carton
-
Small Diameter HDPE Pipe Hot Melt Welding MachineUS$ 0.8 - 88MOQ: 1 Carton
-
HDPE Pipe Hot Melt Welding Machine For Installing HDPE Water Pipes and Fittings Quality ChoiceUS$ 1,470 - 19,500MOQ: 1 Set
-
HDPE Pipe Field Welder HydraulicUS$ 0.8 - 88MOQ: 1 Carton
Place of Origin
Henan, China
Brand Name
MAX, MAX
Model Number
HDPE100
Material
PE
Specification
16~1400mm, According to your requirements
Length
6m,9m,12m
Thickness
2.0~82.4mm, as per industry standard
Standard
ISO9000,ASTM F714 ASNZS 4130 CE,EN12201 ISO4427
HDPE Pipe Socket Welding Machine
Product Show of HDPE Pipe Butt Fusion Machine
Equipment Parameters of HDPE Pipe Butt Fusion Welding Machine
| Specification and Model | DRJ-160 | DRJ-250 | DRJ-315 | DRJ-450 | DRJ-630 | DRJ-800 | DRJ-1000 | DRJ-1200 |
|
Surface Temperature Difference of the Heating Plate |
≤±3℃ | ≤±3℃ | ≤±4℃ | ≤±5℃ | ≤±5℃ | ≤±7℃ | ≤±7℃ | ≤±7℃ |
|
Operating Pressure Range of Hydraulic System |
0-10.0MPa | 0-10.0MPa | 0-10.0MPa | 0-10.0MPa | 0-10.0MPa | 0-16.0MPa | 0-16.0MPa | 0-16.0MPa |
| Power of Heating Plate | 1.2KW | 1.8KW | 2.2KW | 4.8KW | 6.8KW | 10.0KW | 11.5KW | 13KW |
| Power of Milling Cutter | 0.75KW | 1.0KW | 1.0KW | 1.1KW | 1.5KW | 2.2KW | 3.0KW | 3.0KW |
|
Power of Hydraulic Pump Station |
0.75KW | 0.75KW | 0.75KW | 1.1KW | 1.1KW | 1.5KW | 1.5KW | 1.5KW |
| Input Voltage | 220V 50-60HZ | 220V 50-60HZ | 220V 50-60HZ | 380V 50-60HZ | 220V 50-60HZ | 380V 50-60HZ | 380V 50-60HZ | 220V 50-60HZ |
| Input Power | 3.0KW | 3.6KW | 4.0KW | 7KW | 9.5KW | 13.7KW | 16KW | 17.5KW |
|
Welding Specification Range(mm) |
63-160 | 110-250 | 160-315 | 280-450 | 450-630 | 560-800 | 710-1000 | 800-1200 |
| Equipment Weight | 110KG | 130KG | 190KG | 400KG | 600KG | 700KG | 2200KG | 3000KG |
Installation of HDPE Pipe Butt Fusion Machine
The size of HDPE pipe:
HDPE Pipes and Fittings
