Help CenterBottles Jars Hollow Plastic Blow Moulding Machine
Related Products
-
Full-auto Plastic HDPE PP 250ml Jar Blowing Moulding MachineryNegotiableMOQ: 1 Set -
Full-auto Plastic HDPE PP 250ml Jar Blow Molding MachineNegotiableMOQ: 1 Set
-
Plastic Bottle Blowing Machine Price / Blow Moulding MachineNegotiableMOQ: 1 Set
-
Double Station Tetra Die Head Hdpe Bottle Making MachineNegotiableMOQ: 1 Set
-
Automatic Plastic Bottle Making Machines for 1L 1.5L HDPE PP PVC PCNegotiableMOQ: 1 Set
This is hollow plastic blow moulding machine . A wide variety of materials can be used for the machine, which are suitable for producing 100ml to 5L PE bottle. The clam plastic jar making machine plastic jar making machine ping system is a high-precision double-station linear guide, extrusion system using a hard gear reducer and inverter. The die head system adopts central-incoming extrusion die made of special steel, imported hydraulic valve and seal parts with proportional control valve.The control system consists of PLC and Human-machine interface imported from Japan, and automatic temperature control module and imported electrical parts.
hollow plastic blow moulding machine process
hollow plastic blow moulding machine specification
Unit |
Item |
Specification |
Description |
|
Extruding system
|
Screw diameter |
Φ75mm |
Mixing model |
Max. Product Volume |
1L |
Double station and tetra die-head |
|
Screw L/D |
24:1 |
|
|
Material of screw and barrel |
|
38CrMoALA |
|
Plasticizing capacity |
90KG/Hr |
Based on HDPE 5502 |
|
Extruding method |
|
Inverter motor, hardness tooth surface gear box |
|
Driving power |
30KW |
|
|
Screw revolution |
10—90rpm |
|
|
Heating zones |
3 |
Temperature module from Mitsubishi PLC |
|
Heating power |
10KW |
Solid state (SSR) and plug connection for all heaters |
|
Blowers |
3 |
|
|
Cooling function |
Yes |
Cooling water for feeding zone and gear box |
hollow plastic blow moulding machine - die head
hollow plastic blow moulding machine plasticing part
hollow plastic blow moulding machine product
hollow plastic blow moulding machine component brand
Zhangjiagang plastic blow molding machine, loading
Any inuqiry about Zhangjiagang plastic blow molding machine, , blow moulding machine, please contact us! thanks!
