QG-5A Metallurgical Cutting Machine
- 1 Set / Sets per Month
- 4 axis CNC Milling Machine To Router 2d 3d Woodworking Craft
- Stainless Steel Double Kitchen Sink Middle Weld Seam Rolling Machine
- Stainless steel handmade sink hydraulic power of light direct press
- Stainless steel handmade sink R corner press machine Electrical box R corner press machine
- DOING supply photovoltaic solar panels recycling machine
- four-axis welding machine for commercial sink panel and bowl
Product Details
Place of Origin: | Shanghai, China | Brand Name: | Universe | Model Number: | QG-5A |
After-sales Service Provided: | Overseas third-party support available |
Product Description
Description:
l QG5A multifunctional cutting machine is mainly used for cutting irregular general metallographic sample materials such as round cylinder and polygon and protruding platforms, etc.
l This machine adopts double-shells totally closed structure and double quick clamp organization.
l It can guarantee cutting under absolutely safe status, this machine equipped with front, back board, the thickness of sample can be changed arbitrarily, and the speed of entering is controllable.
l In order to avoid the sample organization burns because of being overheated in cutting, this machine is furnished with the strong cooling system, and can avoid little burn of the sample surface while cutting and falling, can increase the cutting section, improve the utilization ratio of cutting emery wheel slice;
l it has convenient advantages in operation, maintenance;
l it is the extremely good apparatus for cutting irregular sample materials.
Technical Specifications:
l Maximum Cutting Cross Section: 100mm×100mm
l Rotate Speed: 2800r/min
l Cutting Disk Size: φ350×2.5×φ32
l Electromotor: Y112M-2, 4KW, 380V, 50Hz
l Dimensions: 800×660×1380mm
l Net Weight: 315Kg
