Specifications
Automatic bending testing machine1. Max testing power: 300KN
2. Used for the brick, stone, cement, concrete.
Concrete Compressive Strength Testing Machine + flexural compression testing machine + Cement Compression Testing Machine
Function and application
YAW-300C Automatic Compression and Flexure Testing Machine is mainly used for compressive strength and flexural test of concrete, cement, brick, stone and other building materials. It can also be used to test the mechanical properties of other materials. It is equipped with computer and can finish bending/compression test automatically. By connecting with a printer, it can save and print testing results. It conforms to GB/T17671-1999.
It is widely used in all kinds of industries and has many advantages, such as high precision, high reliability, low noise, and easy operation and so on.
Main Performance Indicators
1.Max. test force: 300KN(compression)/10kN(bending)
2.Loading rate: 0.3KN / S ~ 10KN / S (compression),50N / s (bending)
3.Error loading speed of ± 5%
4.Size of bearing plate: φ 155mm (compression),80X150mm (bending)
5.Max. stroke of piston:80mm
6.Diameter of piston: 130mm (compression),60mm (bending)
7.Max. pressure of oil:25MPa
8.Rated power of oil pump: 1.52L/min
9.Power of motor: 0.75 kW three-phase
10.Host Dimension mm: 820 × 450 × 1300mm
11.Weight: 500Kg
Automatic bending testing machine
The main interface
Computer control Flexure Testing Machine & Compression Testing Machine,Concrete electro-hydraulic compression testing machine(Dital display),strength cement testing machine,Concrete Pressure Testing Equipment,Compressive Strength Testing machine, Flexure Testing Machine, cement benlding testing machine
