Specifications
Computer Control Compression Testing Machine-automatic overload vprotection function
-automatic constant loading control
300KN Computer Control Compression Testing Machine, Pressure Testing Equipment,Compressive Strength Testing machine
Description:
YAW-300 Computer Control Compression Testing Machine uses high-precision sensor and computer to automatic constant loading control. It has automatic overload vprotection function. It is used to test the compressive strength of building materials such as concrete, cement, airbrick, fire proofing tile, engineering ceramics and building stone in the laboratory of road, bridge and construction.
Main Performance Indicators
-Max.capacity: 300kN
-Test force measurement range: 4% -100% FS
-Test Force showed the relative error: ≤ ± 1%
-Test Force Resolution: 0.01kN
-Rated pressure hydraulic pump: 25MPa
-Loading rate: 0.3KN / S ~ 10KN / S
-Error loading speed: ± 5%
-Pump rated flow: 1.52L/min
-Upper and lower bearing plate size: dia.155mm
-Maximum distance between the upper and lower plate:260mm
-Piston diameter: 130mm
-Piston stroke: 60mm
-Motor Power: 0.75 kW three-phase
-Host Dimension: 870 × 450 × 1400mm
-Weight: 450Kg
Concrete electro-hydraulic compression testing machine(Dital display)
,strength concrete testing machine,Concrete Pressure Testing Equipment,Compressive Strength Testing machine
