Specifications
Cement Automatic Compression Testing Machine-Adopt AC servo system drive the AC servo motor
-Power supply :220V,50Hz
300KN Cement Computer Contolled Automatic Compression Testing Machine
Introduction:
This machine adopt computer auto control, with constant test speed, constant stress, test force keeping and other control mode. The computer realize test data and test curve’display, save,manage function, can print test report. With special fixtures, can test other material compression and flexual testing.
Features:
1. This testing machine adopt AC servo system drive the AC servo motor,by precision reduction gears drives the ball screw,with high test accuracy,low noise.
2. Without pressure oil leakage and proportional valve blocking, low noise, more reliable.
3. Window control and dealing software, design more reasonable. can arbitrarily set pressure value, pressure time, auto calculate test result.
4. Advanced auto control function, can do single or batch test.
5. Auto stop,after sample broken.
6. With over load protection.
Main Specs:
1. Max compression test force:300kN
2. Test force range: 2%~100%FS
3. Test force accuracy:≤±1%
4. Load speed: 0.3~10KN/S
5. Error loading speed: ± 5%
6. Max. stroke of piston:100mm
7. Control and deal mode: Computer constant control and auto dealing
8. Space between upper and lower: 260mm (optional)
9. Pate size : φ 155mm
10. Machine size: 600×560×1500mm
11. Power supply :220V,50Hz
12. Weight: 400 kg
