Specifications
Digital Display Hydraulic Compression Testing Machine1. Max. Load: 3000KN
2. Test space adjustment mode: By motor
3000KN Digital Display Hydraulic Pressure Testing Machine / Compression Testing Machine / Compressive Strength Testing Machine
Application:
3000KN Digital Display Hydraulic Pressure Testing Machine adopts loading hydraulically with accurate and reliable test data. In order to guarantee the accuracy of test load readout, it adopts oil pressure transducer to measure the load, after amplifying, the test load, peak value and loading speed can be displayed digitally. The oil source is installed at the bottom of control cabinet in which there is a double-flow high-pressure piston pump driven by the motor. The hydraulic system is controlled manually with the functions of easy operation, safety and reliability. The test space can be adjusted by the motor.
Technical parameters
1. Max. Load: 3000KN
2. Load display accuracy: ±1%
3. Test space adjustment mode: By motor
4. Distance between upper and lower platen: 330mm
5. Piston stroke: 50mm
6. Size of upper and lower platen: 370×370mm
7. Motor power: 1.1 kW
8. Diameter of Piston: Dia. 310mm
9. Rated pressure of hydraulic: 40MPa
10.Dimension: 1000×600×1500
11. Net Weight: 1600 kG
Testing machine, compression testing machine, comcete compression testing machine, strength testing machine, Pressure Testing Equipment, Compressive Strength Testing machine, cement mortar compression testing machine, cocnrete comressive strength testing machine, civile engineering test apparatus, Pressure Testing Machine
