Electric Curving and Bending Machine

Electric Curving and Bending Machine thumbnail-1
Electric Curving and Bending Machine photo-1
US$ 4,000 - 6,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Hebei, China
Brand Name:
Zhongtuo
Model Number:
ZT-760
Contact Supplier Request Quote Chat Now
Cangzhou Zhongtuo International Trade Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin Xingang
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Hebei, China
Brand Name Zhongtuo
Model Number ZT-760
After-sales Service Provided Engineers available to service machinery overseas

Specifications

1. New design,
2. high automatic,
3. beautiful arc,
4. wide range of radius

Electric curving and bending machine



Electric curving and bending machine



Electric curving and bending machine

Main Parameter



1.The frame: steel welding



2.Material of forming mold: Cr 12 steel with quenched treated 60-62°C



3.Main oil pump press: 32mpa



4.Feeding equipment

1) Turbine worm reducer NMRV050

2) Rack driving

3) DC motor: calculates arc length automatically



5.Forming Speed:press 15-18 times / minute



6.Tolerance of length:+1.0mm



7.Bending thickness:

CQ sheet:0.4mm-0.6mm

G550:0.32mm-0.5mm



8.Minimum bending radius:

 CQ sheet:The minimum bending radius needs to be approximately 300mm.

 G550:The minimum bending radius needs to be approximately 600mm.



9.Bending angles:

 CQ sheet:approximately 5 degrees/time,press 18 times into 90 degrees.

 G550:approximately 3 degrees/time,press 30 times into 90 degrees.



10.Hydraulic system

1) Advanced hydraulic system from Taiwan

2) Power: 5.5kw



11.Automatic Control system

1)Screen: 5.7 inch Taida screen from Taiwan

2)PLC: Taida DVP14ES from Taiwan

3)Coder: ENC-1-1-1T-24 from South Korea

4)Voltage,Frequency,Phase:415V,50HZ,3 Phase.
